AM20C Series
Manufacturer: aimtec
Beta
⌘K
MODULE DC-DC 12VIN 2-OUT -15V/15V -0.667A/0.667A 20W 6-PIN DIP TUBE
| Part | Voltage - Output 1 [Max] [custom] | Voltage - Output 1 [Min] [custom] | Voltage - Output 2 | Features | Voltage - Input (Min) [Min] | Type | Current - Output (Max) | Current - Output (Max) | Operating Temperature [Min] | Operating Temperature [Max] | Applications | Power (Watts) | Number of Outputs | Mounting Type | Voltage - Input (Max) [Max] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Voltage - Isolation | Approval Agency | Efficiency | Current - Output (Max) [Max] | Voltage - Output 1 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 aimtec | 15 V | -15 V | -15 V | Adjustable Output Remote On/Off | 9 V | Isolated Module | 667 mA | 667 mA | -40 C | 75 ░C | ITE (Commercial) | 20 W | 2 | Through Hole | 18 V | 0.39 " | 9.9 mm | 1 in | 1 " | 25.4 mm | 25.4 mm | 1.6 kV | CE cURus | 89 % | ||
 aimtec | Heat Sink Remote On/Off | 13 V | Isolated Module | -40 C | 100 °C | ITE (Commercial) | 20 W | 1 | Through Hole | 70 V | 0.65 in | 16.4 mm | 1.09 in | 1.09 " | 27.6 mm | 27.6 mm | 3000 V | CE | 89 % | 1.67 A | 12 V | |||||
aimtec | Heat Sink Remote On/Off | 13 V | Isolated Module | -40 C | 100 °C | ITE (Commercial) | 20 W | 1 | Through Hole | 70 V | 0.65 in | 16.4 mm | 1.09 in | 1.09 " | 27.6 mm | 27.6 mm | 3000 V | CE | 87 % | 4.5 A | 3.3 V |
