VIPER01 Series

Catalog

VIPERPLUS FAMILY: LOW VOLTAGE ENERGY SAVING FIXED FREQUENCY HIGH VOLTAGE CONVERTER

Part	Mounting Type	Power (Watts)	Supplier Device Package	Voltage - Supply (Vcc/Vdd) [Min]	Voltage - Supply (Vcc/Vdd) [Max]	Output Isolation	Voltage - Start Up	Frequency - Switching	Topology	Operating Temperature [Min]	Operating Temperature [Max]	Duty Cycle	Package / Case	Package / Case	Fault Protection	Voltage - Breakdown
STMicroelectronics VIPER011XS	Surface Mount	7 W	10-SSOP	4.5 V	30 V	Either	8 V	30 kHz	Buck Buck-Boost Flyback	-40 °C	150 °C	80 %	0.154 in 3.9 mm	10-SOP	Current Limiting Over Temperature Over Voltage Short Circuit	800 V
STMicroelectronics VIPER012HS	Surface Mount	7 W	10-SSOP	4.5 V	30 V	Either		120 kHz	Buck Buck-Boost Flyback	-40 °C	150 °C	80 %	0.154 in 3.9 mm	10-SOP	Current Limiting Over Temperature Over Voltage Short Circuit	800 V
STMicroelectronics VIPER012HSTR	Surface Mount	7 W	10-SSOP	4.5 V	30 V	Either	8 V	120 kHz	Buck Buck-Boost Flyback	-40 °C	150 °C	80 %	0.154 in 3.9 mm	10-SOP	Current Limiting Over Temperature Over Voltage Short Circuit	800 V
STMicroelectronics VIPER013XS	Surface Mount	7 W	10-SSOP	4.5 V	30 V	Either		30 kHz	Buck Buck-Boost Flyback	-40 °C	150 °C	80 %	0.154 in 3.9 mm	10-SOP	Current Limiting Over Temperature Over Voltage Short Circuit	800 V
STMicroelectronics VIPER011XSTR	Surface Mount	7 W	10-SSOP	4.5 V	30 V	Either	8 V	30 kHz	Buck Buck-Boost Flyback	-40 °C	150 °C	80 %	0.154 in 3.9 mm	10-SOP	Current Limiting Over Temperature Over Voltage Short Circuit	800 V
STMicroelectronics VIPER012LSTR	Surface Mount	7 W	10-SSOP	4.5 V	30 V	Either	8 V	60 kHz	Buck Buck-Boost Flyback	-40 °C	150 °C	80 %	0.154 in 3.9 mm	10-SOP	Current Limiting Over Temperature Over Voltage Short Circuit	800 V
STMicroelectronics VIPER012XSTR	Surface Mount	7 W	10-SSOP	4.5 V	30 V	Either	8 V	30 kHz	Buck Buck-Boost Flyback	-40 °C	150 °C	80 %	0.154 in 3.9 mm	10-SOP	Current Limiting Over Temperature Over Voltage Short Circuit	800 V
STMicroelectronics VIPER013LS	Surface Mount	7 W	10-SSOP	4.5 V	30 V	Either		60 kHz	Buck Buck-Boost Flyback	-40 °C	150 °C	80 %	0.154 in 3.9 mm	10-SOP	Current Limiting Over Temperature Over Voltage Short Circuit	800 V
STMicroelectronics VIPER013LSTR	Surface Mount	7 W	10-SSOP	4.5 V	30 V	Either	8 V	60 kHz	Buck Buck-Boost Flyback	-40 °C	150 °C	80 %	0.154 in 3.9 mm	10-SOP	Current Limiting Over Temperature Over Voltage Short Circuit	800 V
STMicroelectronics VIPER011LSTR	Surface Mount	7 W	10-SSOP	4.5 V	30 V	Either	8 V	60 kHz	Buck Buck-Boost Flyback	-40 °C	150 °C	80 %	0.154 in 3.9 mm	10-SOP	Current Limiting Over Temperature Over Voltage Short Circuit	800 V
