892-020 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 20POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Contact Type | Read Out | Features | Number of Rows [custom] | Color | Contact Material | Gender | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Termination | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Number of Positions/Bay/Row | Flange Feature | Contact Finish | Card Type | Termination Rows | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Cantilever | Dual | Card Extender | 2 | Black | Copper Alloy | Female | 20 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | 125 °C | -40 C | Solder | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 10 | 4-40 Flush Mount Threaded Insert Top Opening | Gold | Non Specified - Dual Edge | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Cantilever | Dual | 2 | Black | Copper Alloy | Female | 20 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 125 °C | -40 C | Wire Wrap | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 10 | Gold | Non Specified - Dual Edge | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | Single | Black | Copper Alloy | Female | 20 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 125 °C | -40 C | Solder | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 20 Bay/Row | 4-40 Flush Mount Threaded Insert Top Opening | Gold | Non Specified - Single Edge | 1 | 1 | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Cantilever | Dual | 2 | Black | Copper Alloy | Female | 20 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 125 °C | -40 C | Wire Wrap | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 10 | Flush Mount M3 Threaded Insert Top Opening | Gold | Non Specified - Dual Edge | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | Single | Black | Copper Alloy | Female | 20 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 125 °C | -40 C | Solder | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 20 Bay/Row | Floating Bobbin Flush Mount | Gold | Non Specified - Single Edge | 1 | 1 | 0.116 " | 2.95 mm | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Cantilever | Dual | 2 | Black | Copper Alloy | Female | 20 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 125 °C | -40 C | Wire Wrap | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 10 | Gold | Non Specified - Dual Edge | ||||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Cantilever | Dual | 2 | Black | Copper Alloy | Female | 20 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 125 °C | -40 C | Solder | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 10 | 4-40 Flush Mount Threaded Insert Top Opening | Gold | Non Specified - Dual Edge | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Cantilever | Dual | 2 | Black | Copper Alloy | Female | 20 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 125 °C | -40 C | Wire Wrap | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 10 | Flush Mount Side Opening Unthreaded | Gold | Non Specified - Dual Edge | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | Single | Black | Copper Alloy | Female | 20 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 125 °C | -40 C | Wire Wrap | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 20 Bay/Row | Flush Mount Top Opening Unthreaded | Gold | Non Specified - Single Edge | 1 | 1 | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | Single | Black | Copper Alloy | Female | 20 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 125 °C | -40 C | Wire Wrap | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 20 Bay/Row | Gold | Non Specified - Single Edge | 1 | 1 |
