06032 Series

Catalog

CAP CER 2.2PF 200V C0G/NP0 0603

Part	Mounting Type	Applications	Thickness (Max)	Thickness (Max) [Max]	Tolerance	Voltage - Rated	Temperature Coefficient	Package / Case	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Features	Capacitance	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]
Knowles Syfer 060322002P20CQTLSM	MLCC Surface Mount	General Purpose	0.8 mm	0.031 "	0.25 pF	200 VDC	C0G NP0	1608 Metric	0603	-55 C	125 °C	High Q Low Loss Non-Magnetic	2.2 pF	0.031 in	1.6 mm	0.8 mm	0.063 "
Knowles Syfer 060321000330FQTLSM	MLCC Surface Mount	General Purpose	0.8 mm	0.031 "	1 %	100 V	C0G NP0	1608 Metric	0603	-55 C	125 °C	High Q Low Loss Non-Magnetic	33 pF	0.031 in	1.6 mm	0.8 mm	0.063 "
Knowles Syfer 060322004P70BQTLSM	MLCC Surface Mount	General Purpose	0.8 mm	0.031 "	0.1 pF	200 VDC	C0G NP0	1608 Metric	0603	-55 C	125 °C	High Q Low Loss Non-Magnetic	4.7 pF	0.031 in	1.6 mm	0.8 mm	0.063 "
Knowles Syfer 060322003P90BQTLSM	MLCC Surface Mount	General Purpose	0.8 mm	0.031 "	0.1 pF	200 VDC	C0G NP0	1608 Metric	0603	-55 C	125 °C	High Q Low Loss Non-Magnetic	3.9 pF	0.031 in	1.6 mm	0.8 mm	0.063 "
Knowles Syfer 060322005P60BQTLSM	MLCC Surface Mount	General Purpose	0.8 mm	0.031 "	0.1 pF	200 VDC	C0G NP0	1608 Metric	0603	-55 C	125 °C	High Q Low Loss Non-Magnetic	5.6 pF	0.031 in	1.6 mm	0.8 mm	0.063 "
Knowles Syfer 060322001P00BQTLSM	MLCC Surface Mount	General Purpose	0.8 mm	0.031 "	0.1 pF	200 VDC	C0G NP0	1608 Metric	0603	-55 C	125 °C	High Q Low Loss Non-Magnetic	1 pF	0.031 in	1.6 mm	0.8 mm	0.063 "
Knowles Syfer 060321000101JQTLSM	MLCC Surface Mount	General Purpose	0.8 mm	0.031 "	5 %	100 V	C0G NP0	1608 Metric	0603	-55 C	125 °C	High Q Low Loss Non-Magnetic	100 pF	0.031 in	1.6 mm	0.8 mm	0.063 "
Knowles Syfer 060322002P70BQTLSM	MLCC Surface Mount	General Purpose	0.8 mm	0.031 "	0.1 pF	200 VDC	C0G NP0	1608 Metric	0603	-55 C	125 °C	High Q Low Loss Non-Magnetic	2.7 pF	0.031 in	1.6 mm	0.8 mm	0.063 "
Knowles Syfer 060321505P10BQTLSM	MLCC Surface Mount	General Purpose	0.8 mm	0.031 "	0.1 pF	150 V	C0G NP0	1608 Metric	0603	-55 C	125 °C	High Q Low Loss Non-Magnetic	5.1 pF	0.031 in	1.6 mm	0.8 mm	0.063 "
Knowles Syfer 060322000100JQTLSM	MLCC Surface Mount	General Purpose	0.8 mm	0.031 "	5 %	200 VDC	C0G NP0	1608 Metric	0603	-55 C	125 °C	High Q Low Loss Non-Magnetic	10 pF	0.031 in	1.6 mm	0.8 mm	0.063 "
