846-022 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 22POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Mounting Type | Read Out | Card Type | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Termination | Contact Material | Color | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Gender | Number of Positions/Bay/Row | Number of Rows [custom] | Contact Type | Number of Positions | Features | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Right Angle Through Hole | Dual | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Solder | Copper Alloy | Green | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 125 °C | -40 C | 3.18 mm | 0.125 in | Female | 11 | 2 | Cantilever | 22 | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Board Edge Straddle Mount | Dual | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Solder | Copper Alloy | Green | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 125 °C | -40 C | 3.18 mm | 0.125 in | Female | 11 | 2 | Cantilever | 22 | Card Extender | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Through Hole | Dual | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Solder | Copper Alloy | Green | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | 125 °C | -40 C | 3.18 mm | 0.125 in | Female | 11 | 2 | Cantilever | 22 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Through Hole | Single | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Wire Wrap | Copper Alloy | Green | 4-40 Threaded Insert Top Mount Opening | 125 °C | -40 C | 3.18 mm | 0.125 in | Female | 22 | Cantilever | 22 | 1 | 1 | |||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Board Edge Straddle Mount | Dual | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Copper Alloy | Green | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | 125 °C | -40 C | 3.18 mm | 0.125 in | Female | 11 | 2 | Cantilever | 22 | Card Extender | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | Through Hole | Single | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Solder | Copper Alloy | Green | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | 125 °C | -40 C | 3.18 mm | 0.125 in | Female | 22 | Cantilever | 22 | 1 | 1 | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Through Hole | Dual | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Solder | Copper Alloy | Green | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | 125 °C | -40 C | 3.18 mm | 0.125 in | Female | 11 | 2 | Cantilever | 22 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Through Hole | Single | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Wire Wrap | Copper Alloy | Green | 125 °C | -40 C | 3.18 mm | 0.125 in | Female | 22 | Cantilever | 22 | 1 | 1 | ||||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Right Angle Through Hole | Dual | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Solder | Copper Alloy | Green | 0.128 " | Flush Mount Side Opening Unthreaded | 3.25 mm | 125 °C | -40 C | 3.18 mm | 0.125 in | Female | 11 | 2 | Cantilever | 22 | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Through Hole | Dual | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Solder | Copper Alloy | Green | 0.116 " | Floating Bobbin Top Mount Opening | 2.95 mm | 125 °C | -40 C | 3.18 mm | 0.125 in | Female | 11 | 2 | Cantilever | 22 |
