1010975 Series

Catalog

AC/DC CONVERTER 2.5V 100W

Part	Applications	Power (Watts)	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Current - Output 1	Approval Agency	Voltage - Input [Min]	Voltage - Input [Max]	Voltage - Output 1	Number of Outputs	Size / Dimension	Features	Standard Number	Efficiency	Type
Integrated Power Designs 1010975CHCO	ITE (Commercial) Medical	100 W	Chassis Mount	70 °C	0 °C	20 A	CE cURus TUV UKCA	100 VAC	240 VAC	2.5 V	1	2.59 " 4.81 " 33 mm 33.02 mm 65.8 mm 122.2 mm	Adjustable Output Remote Sense Universal Input	60601-1; 62368-1	85 %	Enclosed
Integrated Power Designs 1010975CH	ITE (Commercial) Medical	100 W	Chassis Mount	70 °C	0 °C	20 A	CE cURus TUV UKCA	100 VAC	240 VAC	2.5 V	1	2.59 " 4.81 " 33 mm 33.02 mm 65.8 mm 122.2 mm	Adjustable Output Remote Sense Universal Input	60601-1; 62368-1	85 %	Chassis
