AMSRL Series
Manufacturer: aimtec
Beta
⌘K
DC DC CONVERTER 3.3V 3.3W
| Part | Features | Voltage - Input (Max) [Max] | Current - Output (Max) [Max] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Number of Outputs | Type | Operating Temperature [Max] | Operating Temperature [Min] | Applications | Mounting Type | Voltage - Input (Min) [Min] | Efficiency | Voltage - Output 1 | Power (Watts) | Package / Case | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 aimtec | Adjustable Output Remote On/Off | 36 V | 1 A | 0.6 " | 0.45 in | 15.2 mm | 8.5 mm | 11.4 mm | 0.32 " | 1 | Non-Isolated PoL Module | 85 °C | -40 C | ITE (Commercial) | Surface Mount | 6.5 V | 80 % | 3.3 V | 3.3 W | ||
 aimtec | Adjustable Output Remote On/Off | 72 V | 500 mA | 0.77 in | 0.47 " | 19.5 mm | 5 mm | 11.8 mm | 0.2 " | 1 | Non-Isolated PoL Module | 105 C | -40 °C | ITE (Commercial) | Surface Mount | 9 V | 74 % | 5 V | 10-SMD Module 6 Leads | SMD | |
aimtec | Adjustable Output Remote On/Off | 36 V | 1 A | 0.6 " | 0.45 in | 15.2 mm | 8.5 mm | 11.4 mm | 0.32 " | 1 | Non-Isolated PoL Module | 85 °C | -40 C | ITE (Commercial) | Surface Mount | 16 V | 92 % | 12 V | 12 W | ||
 aimtec | Adjustable Output Remote On/Off | 36 V | 1 A | 0.6 " | 0.34 in | 15.2 mm | 8.3 mm | 8.5 mm | 0.33 in | 1 | Non-Isolated PoL Module | 85 °C | -40 °C | ITE (Commercial) | Surface Mount | 8 V | 85 % | 5 V | 5 W | 10-SMD Module 7 Leads | SMD |
 aimtec | Adjustable Output Remote On/Off | 32 V | 1 A | 0.6 " | 0.45 in | 15.2 mm | 8.5 mm | 11.4 mm | 0.32 " | 1 | Non-Isolated PoL Module | 85 °C | -40 C | ITE (Commercial) | Surface Mount | 4.75 V | 69 % | 1.8 V | 1.8 W |
