AM2D Series

Manufacturer: aimtec

Catalog

Catalog

DC DC CONVERTER 2X9V 2W

...

Part	Voltage - Input (Min) [Min]	Applications	Efficiency	Operating Temperature [Max]	Operating Temperature [Min]	Number of Outputs	Current - Output (Max)	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Package / Case	Voltage - Output 2	Mounting Type	Type	Power (Watts)	Voltage - Output 1	Voltage - Isolation	Voltage - Input (Max) [Max]	Approval Agency	Voltage - Output 1 [Min]	Voltage - Output 1 [Max]	Voltage - Output 1 [Max] [custom]	Voltage - Output 1 [Min] [custom]	Current - Output (Max) [Max]	Current - Output (Max) [Min]
aimtec AM2D-240909DZ	21.6 V	ITE (Commercial)	78 %	85 °C	-40 C	2	111 mA	6 mm	19.5 mm	0.24 "	0.39 "	10 mm	0.77 in	7-SIP Module	9 V	Through Hole	Isolated Module	2 W	9 V	1000 V	26.4 V	CE
aimtec AM2D-1224DZ	10.8 V	ITE (Commercial)		85 °C	-40 C	2	42 mA	6 mm	19.5 mm	0.24 "	0.39 "	10 mm	0.76 "	7-SIP Module	-24 V	Through Hole	Isolated Module	2 W		1000 V	13.2 V	CE	-24 V	24 V
aimtec AM2D-1203DH52Z	10.8 V	ITE (Commercial)	67 %	85 °C	-40 C	2		6 mm	19.5 mm	0.24 "	0.39 "	10 mm	0.76 "	7-SIP Module	-3.3 V	Through Hole	Isolated Module	2 W		5.2 kV	13.2 V	CE			3.3 V	-3.3 V
aimtec AM2D-0503DZ	4.5 V	ITE (Commercial)	65 %	85 °C	-40 C	2		6 mm	19.5 mm	0.24 "	0.39 "	10 mm	0.76 "	7-SIP Module	-3.3 V	Through Hole	Isolated Module	2 W		1000 V	5.5 V	CE			3.3 V	-3.3 V
aimtec AM2D-2405DH30Z	21.6 V	ITE (Commercial)	75 %	85 °C	-40 C	2		6 mm	19.5 mm	0.24 "	0.39 "	10 mm	0.76 "	7-SIP Module	-5 V	Through Hole	Isolated Module	2 W		3000 V	26.4 V	CE	-5 V	5 V
aimtec AM2D-0515SH60Z	4.5 V	ITE (Commercial)		85 °C	-40 C	1		6 mm	19.5 mm	0.24 "	0.39 "	10 mm	0.76 "	7-SIP Module		Through Hole	Isolated Module	2 W	15 V	6000 VDC	5.5 V	CE					134 mA
aimtec AM2D-0507DH52Z	4.5 V	ITE (Commercial)	72 %	85 °C	-40 C	2		6 mm	19.5 mm	0.24 "	0.39 "	10 mm	0.77 in	7-SIP Module 5 Leads	-7.2 V	Through Hole	Isolated Module	2 W	7.2 V	5.2 kV	5.5 V	CE					139 mA	139 mA
aimtec AM2D-2405SH60Z	21.6 V	ITE (Commercial)	79 %	85 °C	-40 C	1		6 mm	19.5 mm	0.24 "	0.39 "	10 mm	0.77 in	7-SIP Module 4 Leads		Through Hole	Isolated Module	2 W	5 V	6000 VDC	26.4 V	CE					400 mA
aimtec AM2D-2407DZ	21.6 V	ITE (Commercial)	75 %	85 °C	-40 C	2		6 mm	19.5 mm	0.24 "	0.39 "	10 mm	0.77 in	7-SIP Module	-7.2 V	Through Hole	Isolated Module	2 W		1000 V	26.4 V	CE	-7.2 V	7.2 V			139 mA	139 mA
aimtec AM2D-1207SZ	10.8 V	ITE (Commercial)	80 %	85 °C	-40 C	1		6 mm	19.5 mm	0.24 "	0.39 "	10 mm	0.77 in	7-SIP Module		Through Hole	Isolated Module	2 W	7.2 V	1000 V	13.2 V	CE					278 mA
