MSS-P Series
Manufacturer: Hirose Electric Co Ltd
Beta
⌘K
CONNECTOR
| Part | Body Material | Dielectric Material | Body Finish | Voltage Rating | Mating Cycles | Center Contact Plating | Operating Temperature [Max] | Operating Temperature [Min] | Contact Termination | Connector Style | Impedance | Fastening Type | Frequency - Max [Max] | Center Contact Material | Connector Type | Mounting Type | Housing Color | Number of Ports | Cable Group | Shield Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Hirose Electric Co Ltd | ||||||||||||||||||||
Hirose Electric Co Ltd | Brass | Polytetrafluoroethylene (PTFE) | Gold | 150 VDC | 3000 | Gold | 85 °C | -40 C | Solder | MSS | 50 Ohms | Snap-On | 1 GHz | Brass | Plug Male Pin | Free Hanging (In-Line) | Gold | 1 | 1.5D-2V | Crimp |
 Hirose Electric Co Ltd | Brass | Polytetrafluoroethylene (PTFE) | Gold | 3000 | Gold | 60 °C | -30 ░C | Solder | MSS | 50 Ohms | Snap-On | 1 GHz | Brass | Plug Male Pin | Free Hanging (In-Line) | Gold | 1 | RG-196 | Crimp | |
 Hirose Electric Co Ltd | Brass | Polytetrafluoroethylene (PTFE) | Gold | 3000 | Gold | 85 °C | -40 C | Solder | MSS | 50 Ohms | Snap-On | 2 GHz | Brass | Plug Male Pin | Free Hanging (In-Line) | Gold | 1 | 1.5D-2V | Crimp |
