LHD-07 Series
Manufacturer: Adam Tech
Beta
⌘K
CONN HEADER VERT 7POS 3.96MM
| Part | Number of Rows | Shrouding | Insulation Material | Pitch - Mating | Pitch - Mating | Number of Positions | Insulation Color | Mounting Type | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Shape | Contact Length - Post | Contact Length - Post | Termination | Contact Material | Style | Fastening Type | Insulation Height [z] | Insulation Height [z] | Current Rating (Amps) | Material Flammability Rating | Contact Finish - Post | Number of Positions Loaded | Contact Length - Mating | Contact Length - Mating | Connector Type | Overall Contact Length | Overall Contact Length | Insulation Height | Insulation Height | Contact Length - Post [x] | Contact Length - Post [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Adam Tech | 1 | Shrouded - 1 Wall | Nylon 6/6 Polyamide (PA66) | 3.96 mm | 0.156 in | 7 | White | Through Hole | Male Pin | -40 C | 105 ░C | Square | 0.142 in | 3.6 mm | Solder | Brass | Board to Cable/Wire | Friction Lock | 10.8 mm | 0.425 in | 7 A | UL94 V-2 | Tin | All | 11.38 mm | 0.448 in | Header | 18.16 mm | 0.715 in | ||||
 Adam Tech | 1 | Shrouded - 1 Wall | Glass Filled Nylon 6/6 Polyamide (PA66) | 3.96 mm | 0.156 in | 7 | White | Right Angle Through Hole | Male Pin | -40 C | 85 °C | Square | Solder | Brass | Board to Cable/Wire | Friction Lock | 7 A | UL94 V-0 | Tin | All | 11.4 mm | 0.449 in | Header | 0.125 in | 3.18 mm | 0.126 " | 3.2 mm | ||||||
 Adam Tech | 1 | Shrouded - 1 Wall | Glass Filled Nylon 6/6 Polyamide (PA66) | 3.96 mm | 0.156 in | 7 | White | Right Angle Through Hole | Male Pin | -40 C | 85 °C | Square | Solder | Brass | Board to Cable/Wire | Friction Lock | 7 A | UL94 V-2 | Tin | All | 11.4 mm | 0.449 in | Header | 0.3 in | 7.62 mm | 0.126 " | 3.2 mm | ||||||
 Adam Tech | 1 | Shrouded - 1 Wall | Glass Filled Nylon 6/6 Polyamide (PA66) | 3.96 mm | 0.156 in | 7 | White | Right Angle Through Hole | Male Pin | -40 C | 85 °C | Square | Solder | Brass | Board to Cable/Wire | Friction Lock | 7 A | UL94 V-0 | Tin | All | 11.4 mm | 0.449 in | Header | 0.125 in | 3.18 mm | 0.126 " | 3.2 mm | ||||||
 Adam Tech | 1 | Shrouded - 1 Wall | Glass Filled Nylon 6/6 Polyamide (PA66) | 3.96 mm | 0.156 in | 7 | White | Right Angle Through Hole | Male Pin | -40 C | 85 °C | Square | Solder | Brass | Board to Cable/Wire | Friction Lock | 7 A | UL94 V-2 | All | 11.4 mm | 0.449 in | Header | 0.3 in | 7.62 mm | 0.126 " | 3.2 mm |
