ZX62 Series
Manufacturer: Hirose Electric Co Ltd
Beta
⌘K
CONN RCPT USB2.0 MICRO B SMD
| Part | Insulation Color | Shell/Shielding Material | Contact Finish | Material Flammability Rating | Specifications | Mating Cycles | Features | Termination | Voltage - Rated | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Feature | Mounting Type | Current Rating (Amps) | Connector Type | Number of Ports | Number of Contacts | Shielding | Gender |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Hirose Electric Co Ltd | Black | Stainless Steel | Gold | UL94 V-0 | USB 2.0 | 10000 | Pick and Place Solder Retention | Solder | 30 VAC | 85 °C | -30 ░C | Horizontal Mid Mount | Board Edge Cutout Surface Mount Through Hole Right Angle | 1.8 A | USB - micro B | 1 | 5 | Shielded | Receptacle |
 Hirose Electric Co Ltd | Gray | Stainless Steel | Gold | UL94 V-0 | USB 2.0 | 10000 | Pick and Place Solder Retention | Solder | 30 VAC | 85 °C | -30 ░C | Horizontal Reverse Mount | Right Angle Surface Mount | 1.8 A | USB - micro AB | 1 | 5 | Shielded | Receptacle |
 Hirose Electric Co Ltd | Black | Stainless Steel | Gold | UL94 V-0 | USB 2.0 | 10000 | Pick and Place Solder Retention | Solder | 30 VAC | 85 °C | -30 ░C | Bottom Mount Horizontal | Surface Mount Right Angle Through Hole | 1.8 A | USB - micro B | 1 | 5 | Shielded | Receptacle |
 Hirose Electric Co Ltd | Black | Gold | UL94 V-0 | USB 2.0 | 10000 | Solder | 30 VAC | 85 °C | -30 ░C | Horizontal | Surface Mount Right Angle Through Hole | 1.8 A | USB - micro B | 1 | 5 | Shielded | Receptacle | ||
 Hirose Electric Co Ltd | Gray | Stainless Steel | Gold | UL94 V-0 | USB 2.0 | 10000 | Pick and Place Solder Retention | Solder | 30 VAC | 85 °C | -30 ░C | Bottom Mount Horizontal | Right Angle Surface Mount | 1 A | USB - micro AB | 1 | 5 | Shielded | Receptacle |
 Hirose Electric Co Ltd | Black | Stainless Steel | Gold | UL94 V-0 | USB 2.0 | 10000 | Pick and Place Cap Solder Retention | Solder | 30 VAC | 85 °C | -30 ░C | Bottom Mount Horizontal | Surface Mount Right Angle Through Hole | 1.8 A | USB - micro B | 1 | 5 | Shielded | Receptacle |
 Hirose Electric Co Ltd | Gray | Stainless Steel | Gold | UL94 V-0 | USB 2.0 | 10000 | Pick and Place Solder Retention | Solder | 30 VAC | 85 °C | -30 ░C | Bottom Mount Horizontal | Surface Mount Right Angle Through Hole | 1 A | USB - micro AB | 1 | 5 | Shielded | Receptacle |
Hirose Electric Co Ltd | Gray | Gold | UL94 V-0 | USB 2.0 | 10000 | Solder | 30 VAC | 85 °C | -30 ░C | Horizontal | Right Angle Surface Mount | 1 A 1.8 A 100 mA | USB - micro AB | 1 | 5 | Shielded | Receptacle | ||
 Hirose Electric Co Ltd | Black | Stainless Steel | Gold | UL94 V-0 | USB 2.0 | 10000 | Pick and Place Solder Retention | Solder | 30 VAC | 85 °C | -30 ░C | Bottom Mount Horizontal | Right Angle Surface Mount | 1 A | USB - micro B | 1 | 5 | Shielded | Receptacle |
Hirose Electric Co Ltd | Black | Gold | UL94 V-0 | USB 2.0 | 10000 | Solder | 30 VAC | 85 °C | -30 ░C | Horizontal | Surface Mount Right Angle Through Hole | 1.8 A | USB - micro AB | 1 | 5 | Shielded | Receptacle |
