ADL5523 Series
Manufacturer: Analog Devices
Beta
⌘K
RF AMP SINGLE LNA 4GHZ 5V 8-PIN LFCSP EP T/R
| Part | Package / Case | Voltage - Supply [Max] | Voltage - Supply [Min] | Supplier Device Package | Test Frequency | P1dB | RF Type | Noise Figure | Current - Supply | Frequency [Min] | Frequency [Max] | Gain | Mounting Type | Frequency | For Use With/Related Products | Supplied Contents | Type | Current - Supply [Min] | Current - Supply [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices | 8-VFDFN Exposed Pad CSP | 5 V | 3 V | 8-LFCSP-VD (3x3) | 900 MHz | 21 dBm | General Purpose | 0.8 dB | 60 mA | 400 MHz | 4 GHz | 21.5 dB | Surface Mount | ||||||
 Analog Devices | 433.92 MHz | ADL5523 | Board(s) | Amplifier | |||||||||||||||
Analog Devices | 8-WFDFN Exposed Pad CSP | 5 V | 3 V | 8-LFCSP (3x3) | 1.95 GHz | 21.2 dBm | 0.8 dB | 400 MHz | 4 GHz | 21.5 dB | Surface Mount | 30 mA | 60 mA |
