SQ4435 Series

Catalog

MOSFET P-CHANNEL 30V 15A 8SOIC

Part	Drive Voltage (Max Rds On, Min Rds On)	Mounting Type	Technology	Current - Continuous Drain (Id) @ 25°C	Grade	Drain to Source Voltage (Vdss)	Rds On (Max) @ Id, Vgs	FET Type	Supplier Device Package	Package / Case	Package / Case [y]	Package / Case [x]	Gate Charge (Qg) (Max) @ Vgs [Max]	Input Capacitance (Ciss) (Max) @ Vds	Power Dissipation (Max) [Max]	Qualification	Vgs(th) (Max) @ Id	Vgs (Max)	Operating Temperature [Min]	Operating Temperature [Max]
Vishay General Semiconductor - Diodes Division SQ4435EY-T1_BE3	4.5 V 10 V	Surface Mount	MOSFET (Metal Oxide)	15 A	Automotive	30 V	18 mOhm	P-Channel	8-SOIC	8-SOIC	3.9 mm	0.154 in	58 nC	2170 pF	6.8 W	AEC-Q101	2.5 V	20 V	-55 °C	175 ░C
Vishay General Semiconductor - Diodes Division SQ4435EY-T1_GE3	4.5 V 10 V	Surface Mount	MOSFET (Metal Oxide)	15 A		30 V	18 mOhm	P-Channel	8-SOIC	8-SOIC	3.9 mm	0.154 in	58 nC	2170 pF	6.8 W		2.5 V	20 V	-55 °C	175 ░C
