A17733 Series

Manufacturer: Laird Technologies - Thermal Materials

Catalog

THERM PAD 228.6MMX228.6MM W/ADH

Part	Material	Outline [x]	Outline [y]	Type	Thermal Conductivity	Adhesive	Color	Shelf Life Start	Shape	Shelf Life	Thickness	Thickness	Thickness [z]	Thickness [z]
Laird Technologies - Thermal Materials A17733-17	Elastomer	228.6 mm	228.6 mm	Gap Filler Pad Sheet	1.2 W/m-K	Adhesive - One Side	Yellow	Date of Shipment	Square	24 Months	4.32 mm	0.17 in
Laird Technologies - Thermal Materials A17733-11	Elastomer	228.6 mm	228.6 mm	Gap Filler Pad Sheet	1.2 W/m-K	Adhesive - One Side	Yellow	Date of Shipment	Square	24 Months			2.79 mm	0.11 in
Laird Technologies - Thermal Materials A17733-06	Elastomer	228.6 mm	228.6 mm	Gap Filler Pad Sheet	1.2 W/m-K	Adhesive - One Side	Yellow	Date of Shipment	Square	24 Months	1.524 mm	0.06 in
Laird Technologies - Thermal Materials A17733-04	Elastomer	228.6 mm	228.6 mm	Gap Filler Pad Sheet	1.2 W/m-K	Adhesive - One Side	Yellow	Date of Shipment	Square	24 Months	1.016 mm	0.04 in
Laird Technologies - Thermal Materials A17733-18	Elastomer	228.6 mm	228.6 mm	Gap Filler Pad Sheet	1.2 W/m-K	Adhesive - One Side	Yellow	Date of Shipment	Square	24 Months	4.57 mm	0.18 in
Laird Technologies - Thermal Materials A17733-03	Elastomer	228.6 mm	228.6 mm	Gap Filler Pad Sheet	1.2 W/m-K	Adhesive - One Side	Yellow	Date of Shipment	Square	24 Months	0.762 mm	0.03 in
Laird Technologies - Thermal Materials A17733-15	Elastomer	228.6 mm	228.6 mm	Gap Filler Pad Sheet	1.2 W/m-K	Adhesive - One Side	Yellow	Date of Shipment	Square	24 Months	3.81 mm	0.15 in
Laird Technologies - Thermal Materials A17733-16	Elastomer	228.6 mm	228.6 mm	Gap Filler Pad Sheet	1.2 W/m-K	Adhesive - One Side	Yellow	Date of Shipment	Square	24 Months	4.06 mm	0.16 in
Laird Technologies - Thermal Materials A17733-02	Elastomer	228.6 mm	228.6 mm	Gap Filler Pad Sheet	1.2 W/m-K	Adhesive - One Side	Yellow	Date of Shipment	Square	24 Months	0.508 mm	0.02 in
Laird Technologies - Thermal Materials A17733-05	Elastomer	228.6 mm	228.6 mm	Gap Filler Pad Sheet	1.2 W/m-K	Adhesive - One Side	Yellow	Date of Shipment	Square	24 Months	50 mils	0.05 in
