BXEM-50 Series
Manufacturer: BRIDGELUX
Beta
⌘K
LED GEN2 COOL WHITE 5000K 3030
| Part | Thermal Resistance of Package | Current - Test | CCT (K) | Mounting Type | CRI (Color Rendering Index) | Color | Voltage - Forward (Vf) (Typ) | Flux @ 85°C, Current - Test | Package / Case | Package / Case | Viewing Angle | Supplier Device Package | Lumens/Watt @ Current - Test | Current - Max [Max] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Height - Seated (Max) | Height - Seated (Max) [Max] [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BRIDGELUX | 12 °C/W | 300 mA | 5000 K | Surface Mount | 70 | Cool White | 3 V | 113 lm | 3030 Metric | 1212 | 120 ° | 3030 | 126 lm/W | 400 mA | 3 mm | 0.118 in | 3 mm | 0.118 " | 0.62 mm | 0.024 " |
 BRIDGELUX | 12 °C/W | 150 mA | 5000 K | Surface Mount | 70 | Cool White | 6 V | 113 lm | 3030 Metric | 1212 | 120 ° | 3030 | 126 lm/W | 240 mA | 3 mm | 0.118 in | 3 mm | 0.118 " | 0.62 mm | 0.024 " |
