GaAs pHEMT MMIC Low Noise Amplifier, 4.8 to 6.0 GHz
Key Features
• Noise figure: 1.1 dB
• Gain: 14.5 dB
• Output IP3: +29.5 dBm
• Single supply: +3V to +5V
• 16 lead 3x3mm QFN package: 9 mm2
Description
AI
The HMC717ALP3E is a GaAs PHEMT MMIC Low Noise Amplifier that is ideal for fixed wireless and LTE/WiMAX/4G basestation front-end receivers operating between 4.8 and 6.0 GHz. The amplifier has been optimized to provide 1.1 dB noise figure, 14.5 dB gain and +29.5 dBm output IP3 from a single supply of +5V. Input and output return losses are excellent and the LNA requires minimal external matching and bias decoupling components. The HMC717ALP3E can be biased with +3V to +5V and features an externally adjustable supply current which allows the designer to tailor the linearity performance of the LNA for each application.ApplicationsFixed wireless and LTE/WiMAX/4GBTS and infrastructureRepeaters and FemtocellsPublic safety radioAccess points
