AMEOF5 Series
Manufacturer: aimtec
Beta
⌘K
AC/DC CONVERTER 15V 5.1W
| Part | Load Regulation | Weight | Weight | Line Regulation | Type | Current - Output (Max) [Max] | Voltage - Output 1 | Voltage - Input [Min] | Voltage - Input [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Package / Case | Power (Watts) | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Mounting Type | Number of Outputs | Applications | Efficiency | Size / Dimension [y] | Size / Dimension [z] | Load Regulation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 aimtec | ±1% | 0.017 lb | 7.5 g | 1 % | Open Frame | 340 mA | 15 V | 90 VAC 100 V | 528 VAC 745 VDC | -40 °C | 85 °C | 16-SIP Module 6 Leads | 5.1 W | 0.94 in | 1.75 " | 0.51 in | 24 mm | 13 mm | 44.5 mm | Through Hole | 1 | ITE (Commercial) | 76 % | |||
aimtec | ±1% | 0.017 lb | 7.5 g | 1 % | Open Frame | 560 mA | 9 V | 90 VAC 100 V | 528 VAC 745 VDC | -40 °C | 85 °C | 16-SIP Module 6 Leads | 5 W | 0.51 in | 1.75 " | 0.94 " | 44.5 mm | Through Hole | 1 | ITE (Commercial) | 70 % | 13 mm | 24 mm | |||
 aimtec | ±1% | 0.017 lb | 7.5 g | 1 % | Open Frame | 850 mA | 3.3 V | 90 VAC 100 V | 528 VAC 745 VDC | -40 °C | 85 °C | 16-SIP Module 6 Leads | 2.8 W | 0.94 in | 1.75 " | 0.51 in | 24 mm | 13 mm | 44.5 mm | Through Hole | 1 | ITE (Commercial) | 63 % | |||
aimtec | 0.017 lb | 7.5 g | 1.5 % | Open Frame | 420 mA | 12 V | 90 VAC | 528 VAC | -40 °C | 85 °C | 16-SIP Module 6 Leads | 5 W | 1.75 " | 0.95 in | 0.51 in | 44.5 mm | 13 mm | 24 mm | Through Hole | 1 | ITE (Commercial) | 75 % | 2.5 % | |||
aimtec | ±1% | 0.017 lb | 7.5 g | 1 % | Open Frame | 210 mA | 24 V | 90 VAC 100 V | 528 VAC 745 VDC | -40 °C | 85 °C | 16-SIP Module 6 Leads | 5 W | 0.94 in | 1.75 " | 0.51 in | 24 mm | 13 mm | 44.5 mm | Through Hole | 1 | ITE (Commercial) | 76 % | |||
 aimtec | ±1% | 0.015 lb | 7 g | 0.5 % | Open Frame | 420 mA | 12 V | 85 VAC 100 V | 305 VAC 430 VDC | -40 °C | 85 °C | 14-SIP Module 6 Leads | 5 W | 0.79 in | 1.65 in | 0.54 " | 20 mm | 13.7 mm | 42 mm | Through Hole | 1 | Household Appliances ITE (Commercial) | 76 % | |||
 aimtec | 0.017 lb | 7.5 g | 1.5 % | Open Frame | 210 mA | 24 V | 90 VAC | 528 VAC | -40 °C | 85 °C | 16-SIP Module 6 Leads | 5 W | 1.75 " | 0.95 in | 0.51 in | 44.5 mm | 13 mm | 24 mm | Through Hole | 1 | ITE (Commercial) | 75 % | 2.5 % | |||
 aimtec | 1.5 % | Open Frame | 1 A | 5 V | 85 VAC | 305 VAC | -40 °C | 85 °C | 12-SIP Module 6 Leads | 5 W | 0.71 in | 1.38 " | 0.43 in | 18 mm | 11 mm | 35 mm | Through Hole | 1 | Household Appliances ITE (Commercial) | 74 % | 3 % | |||||
aimtec | ±1% | 0.015 lb | 7 g | 0.5 % | Open Frame | 1 A | 5 V | 85 VAC 100 V | 305 VAC 430 VDC | -40 °C | 85 °C | 14-SIP Module 6 Leads | 5 W | 0.79 in | 1.65 in | 0.54 " | 20 mm | 13.7 mm | 42 mm | Through Hole | 1 | Household Appliances ITE (Commercial) | 74 % | |||
aimtec | ±1% | 0.017 lb | 7.5 g | 1 % | Open Frame | 850 mA | 5 V | 90 VAC 100 V | 528 VAC 745 VDC | -40 °C | 85 °C | 16-SIP Module 6 Leads | 4.3 W | 0.94 in | 1.75 " | 0.51 in | 24 mm | 13 mm | 44.5 mm | Through Hole | 1 | ITE (Commercial) | 67 % |
