AM3G-1224 Series
Manufacturer: aimtec
Beta
⌘K
DC DC CONVERTER 24V 3W
| Part | Current - Output (Max) [Max] | Voltage - Input (Min) [Min] | Type | Number of Outputs | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Efficiency | Package / Case | Mounting Type | Voltage - Output 1 | Power (Watts) | Applications | Voltage - Input (Max) [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Features | Voltage - Isolation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 aimtec | 125 mA | 9 V | Isolated Module | 1 | 0.47 " | 9.5 mm | 0.87 in | 12 mm | 0.37 in | 22 mm | 81 % | 8-SIP Module | Through Hole | 24 V | 3 W | ITE (Commercial) | 18 V | -40 C | 100 °C | Remote On/Off | 3000 V |
