SPC574K72E5 Series

32-bit Power Architecture MCU for Automotive Applications

Catalog

32-bit Power Architecture MCU for Automotive Applications

Part	Speed [Max]	Speed [Min]	Qualification	Grade	Connectivity	Voltage - Supply (Vcc/Vdd) [Max]	Voltage - Supply (Vcc/Vdd) [Min]	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Core Processor	Core Size	Core Size	Program Memory Size	RAM Size	Supplier Device Package	EEPROM Size	Program Memory Type	Oscillator Type	Data Converters	Mounting Type
STMicroelectronics SPC574K72E5C6FAR	160 MHz	80 MHz	AEC-Q100	Automotive	CANbus Ethernet FlexRay I2C LINbus SPI UART/USART	5.5 V	3 V	144-TQFP Exposed Pad	125 °C	-40 °C	e200z2 e200z4	32 Bit	Tri-Core	2.5 MB	64 K	144-eTQFP (20x20)	64 K	FLASH	Internal	16b Sigma-Delta A/D 12b SAR	Surface Mount

Catalog

32-bit Power Architecture MCU for Automotive Applications

Description

This family of MCUs targets automotive powertrain controller applications for four-cylinder gasoline and diesel engines, chassis control applications, transmission control applications, steering and braking applications, as well as low-end hybrid applications. Many of the applications are considered to be functionally safe and the family is designed to achieve ISO26262 ASIL-D compliance.
