FDPC1012S Series

PowerTrench Power Clip 25V Asymetric Dual N-Channel MOSFET

Catalog

PowerTrench Power Clip 25V Asymetric Dual N-Channel MOSFET

Part	Rds On (Max) @ Id, Vgs	Power - Max	Drain to Source Voltage (Vdss)	Configuration	Input Capacitance (Ciss) (Max) @ Vds	Technology	Vgs(th) (Max) @ Id	Mounting Type	Package / Case	Current - Continuous Drain (Id) @ 25°C	Operating Temperature [Min]	Operating Temperature [Max]	Gate Charge (Qg) (Max) @ Vgs	Gate Charge (Qg) (Max) @ Vgs
ON Semiconductor FDPC1012S	2.2 mOhm 7 mOhm	800 mW 900 mW	25 V	2 N-Channel (Dual) Asymmetrical	1075 pF 3456 pF	MOSFET (Metal Oxide)	2.2 V 2.2 V	Surface Mount	8-PowerWDFN	13 A 26 A 35 A 88 A	-55 °C	150 °C	8 nC	25 nC
ON Semiconductor FDPC1002S
ON Semiconductor FDPC1012S	2.2 mOhm 7 mOhm	800 mW 900 mW	25 V	2 N-Channel (Dual) Asymmetrical	1075 pF 3456 pF	MOSFET (Metal Oxide)	2.2 V 2.2 V	Surface Mount	8-PowerWDFN	13 A 26 A 35 A 88 A	-55 °C	150 °C	8 nC	25 nC

Catalog

PowerTrench Power Clip 25V Asymetric Dual N-Channel MOSFET

Key Features

• Q1: N-ChannelMax rDS(on) = 7.0 mΩ at VGS = 4.5 V, ID = 12 AQ2: N-ChannelMax rDS(on) = 2.2 mΩ at VGS = 4.5 V, ID = 23 A

• Low inductance packaging shortens rise/fall times, resulting in lower switching losses

• MOSFET integration enables optimum layout for lower circuitinductance and reduced switch node ringing

• RoHS Compliant

Description

This device includes two specialized N-Channel MOSFETs in a dual package. The switch node has been internally connected to enable easy placement and routing of synchronous buck converters. The control MOSFET (Q1) and synchronous SyncFET (Q2) have been designed to provide optimal power efficiency.
