VCO with Fo/2 & Divide-by-4 SMT, 9.5 - 10.8 GHz
Key Features
• Triple Output:Fo= 9.5 - 10.8 GHzFo/2= 4.75 - 5.4 GHzFo/4= 2.38 - 2.7 GHz
• Pout: +11 dBm
• Phase Noise:-110 dBc/Hz @ 100 kHz Typical
• No External Resonator Needed
• QFN Leadless SMT Package, 25 mm2
Description
AI
The HMC530LP5(E) is a GaAs InGaP Heterojunction Bipolar Transistor (HBT) MMIC VCOs. The HMC530LP5(E) integrates resonators, negative resistance devices, varactor diodes and feature half frequency and divide-by-4 outputs. The VCO's phase noise performance is excellent over temperature, shock and process due to the oscillator's monolithic structure. Power output is +11 dBm typical from a +5V supply voltage. The prescaler and RF/2 functions can be disabled to conserve current if not required. The voltage controlled oscillator is packaged in a leadless QFN 5x5 mm surface mount package, and requires no external matching components.APPLICATIONSPoint-to-Point RadiosPoint-to-Multi-Point RadiosTest Equipment & Industrial ControlsSATCOMMilitary End-Use
