ADS1158 Series
Manufacturer: Texas Instruments
Beta
⌘K
16-BIT, 125KSPS, 16-CH DELTA-SIGMA ADC W/ FAST CHANNEL SCAN & AUTOMATIC SEQUENCER
| Part | Mounting Type | Number of Inputs | Data Interface | Voltage - Supply, Analog | Reference Type | Number of A/D Converters | Architecture | Operating Temperature [Min] | Operating Temperature [Max] | Package / Case | Input Type | Configuration | Number of Bits | Voltage - Supply, Digital [Max] | Voltage - Supply, Digital [Min] | Supplier Device Package | Power (Typ) @ Conditions | Supplied Contents | Input Range [Max] | Input Range [Min] | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | Surface Mount | 16 8 | SPI | 5 V | External | 1 | Sigma-Delta | -40 °C | 105 ░C | 48-VFQFN Exposed Pad | Differential Single Ended | MUX-ADC | 16 | 5.25 V | 2.7 V | 48-VQFN (7x7) | |||||
Texas Instruments | SPI | 1 | 16 | 42 mW | Board(s) | 5 V | 0 V | ADS1158 | |||||||||||||
Texas Instruments | Surface Mount | 16 8 | SPI | 5 V | External | 1 | Sigma-Delta | -40 °C | 105 ░C | 48-VFQFN Exposed Pad | Differential Single Ended | MUX-ADC | 16 | 5.25 V | 2.7 V | 48-VQFN (7x7) |
