THN 15 Series
Manufacturer: Traco Power
Beta
⌘K
DC DC CONVERTER 24V 15W
| Part | Current - Output (Max) [Max] | Voltage - Input (Min) [Min] | Type | Number of Outputs | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Voltage - Output 1 | Power (Watts) | Features | Package / Case | Voltage - Input (Max) [Max] | Applications | Voltage - Isolation | Efficiency | Current - Output (Max) | Voltage - Output 2 | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Traco Power | 625 mA | 18 V | Isolated Module | 1 | Through Hole | 105 C | -40 °C | 0.39 " | 9.9 mm | 1 in | 1 " | 25.4 mm | 25.4 mm | 24 V | 15 W | OCP OVP Remote On/Off SCP | 6-DIP Module | 36 V | ITE (Commercial) | 1.6 kV | 91 % | |||
 Traco Power | 3 A | 18 V | Isolated Module | 1 | Through Hole | 90 °C | -40 °C | 0.39 " | 9.9 mm | 1 in | 1 " | 25.4 mm | 25.4 mm | 5 V | 15 W | OVP Remote On/Off SCP UVLO | 6-DIP Module | 75 V | ITE (Commercial) Railway | 3000 V | 89 % | |||
Traco Power | 1 A | 9 V | Isolated Module | 1 | Through Hole | 90 °C | -40 °C | 0.39 " | 9.9 mm | 1 in | 1 " | 25.4 mm | 25.4 mm | 15 V | 15 W | OVP Remote On/Off SCP UVLO | 6-DIP Module | 36 V | ITE (Commercial) Railway | 3000 V | 89 % | |||
Traco Power | 9 V | Isolated Module | 2 | Through Hole | 90 °C | -40 °C | 0.39 " | 9.9 mm | 1 in | 1 " | 25.4 mm | 25.4 mm | 15 V | 15 W | OVP Remote On/Off SCP UVLO | 6-DIP Module | 36 V | ITE (Commercial) Railway | 3000 V | 89 % | 500 mA | -15 V | ||
 Traco Power | 36 V | Isolated Module | 2 | Through Hole | 85 °C | -40 °C | 0.39 " | 9.9 mm | 1 in | 1 " | 25.4 mm | 25.4 mm | 5 V | 15 W | OVP Remote On/Off SCP | 6-DIP Module | 75 V | ITE (Commercial) | 1.5 kV | 85 % | 1.5 A | -5 V | ||
Traco Power | 18 V | Isolated Module | 2 | Through Hole | 85 °C | -40 °C | 0.39 " | 9.9 mm | 1 in | 1 " | 25.4 mm | 25.4 mm | 24 V | 15 W | OVP Remote On/Off SCP | 6-DIP Module | 36 V | ITE (Commercial) | 1.5 kV | 90 % | -24 V | |||
 Traco Power | 18 V | Isolated Module | 2 | Through Hole | 85 °C | -40 °C | 0.39 " | 9.9 mm | 1 in | 1 " | 25.4 mm | 25.4 mm | 24 V | 15 W | OVP Remote On/Off SCP UVLO | 6-DIP Module | 75 V | ITE (Commercial) | 1.6 kV | 90 % | -24 V | CB cURus | ||
Traco Power | 1.3 A | 36 V | Isolated Module | 1 | Through Hole | 85 °C | -40 °C | 0.39 " | 9.9 mm | 1 in | 1 " | 25.4 mm | 25.4 mm | 12 V | 15 W 16 W | OVP Remote On/Off SCP | 6-DIP Module | 75 V | ITE (Commercial) | 1.5 kV | 88 % | |||
Traco Power | 1.3 A | 18 V | Isolated Module | 1 | Through Hole | 90 °C | -40 °C | 0.39 " | 9.9 mm | 1 in | 1 " | 25.4 mm | 25.4 mm | 12 V | 15 W 16 W | OVP Remote On/Off SCP UVLO | 6-DIP Module | 75 V | ITE (Commercial) Railway | 3000 V | 89 % | |||
Traco Power | 9 V | Isolated Module | 2 | Through Hole | 105 C | -40 °C | 0.39 " | 9.9 mm | 1 in | 1 " | 25.4 mm | 25.4 mm | 5 V | 15 W | OCP OVP Remote On/Off SCP | 6-DIP Module | 18 V | ITE (Commercial) | 1.6 kV | 86 % | 1.5 A | -5 V |
