07530GA Series

Blowers & Centrifugal Fans DC Blower, 75x30mm, 24VDC, 13.1CFM, Lead Wires

Manufacturer: NMB TECHNOLOGIES

Catalog

Blowers & Centrifugal Fans DC Blower, 75x30mm, 24VDC, 13.1CFM, Lead Wires

Catalog

Blowers & Centrifugal Fans DC Blower, 75x30mm, 24VDC, 13.1CFM, Lead Wires

Part	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Rated	Termination	RPM	Noise	Fan Type	Width [y]	Power (Watts)	Size / Dimension	Size / Dimension [x]	Size / Dimension [y]	Air Flow	Air Flow	Bearing Type	Static Pressure	Static Pressure	Features	Voltage Range [Max]	Voltage Range [Min]	Current Rating (Amps)	Material - Frame	Material - Blade	Weight	Weight	Approval Agency	Lifetime @ Temp.	Size / Dimension [z]	Operating Temperature [Max]	Operating Temperature [Min]
NMB TECHNOLOGIES 07530GA-12J-AT-00	70 °C	-10 °C	12 VDC	3 Wire Leads	2000 RPM	28 dB	Blower	30 mm	1.2 W	Square/Rounded	75.7 mm	75.7 mm	6.7 CFM	0.188 mł/min	Ball	39.8 Pa	0.16 in H2O	Auto Restart Speed Sensor (Tach)
NMB TECHNOLOGIES BG0703-B044-00L-00	70 °C	-10 °C	12 VDC	3 Wire Leads	3000 RPM	38.5 dB	Blower	30 mm	3.48 W	Square/Rounded	75.7 mm	75.7 mm	10.6 CFM	0.297 m³/min	Ball	110 Pa	0.441 in H2O	Locked Rotor Sensor	13 V	6 VDC	0.29 A	Plastic	Plastic	0.198 lb	89.81 g	CE CSA UL VDE
NMB TECHNOLOGIES 07530GA-24M-AT-00	70 °C	-10 °C	24 VDC	3 Wire Leads	3000 RPM	38.5 dB	Blower	30 mm	3.6 W	Square/Rounded	75.7 mm	75.7 mm	10.5 CFM	0.294 mł/min	Ball	109.6 Pa	0.44 in H2O	Auto Restart Speed Sensor (Tach)
NMB TECHNOLOGIES 07530GA-12M-AT-00	70 °C	-10 °C	12 VDC	3 Wire Leads	3000 RPM	38.5 dB	Blower	30 mm	3.48 W	Square/Rounded	75.7 mm	75.7 mm	10.5 CFM	0.294 mł/min	Ball	109.6 Pa	0.44 in H2O	Auto Restart Speed Sensor (Tach)
NMB TECHNOLOGIES BG0703-B055-000-00	70 °C	-10 °C	24 VDC	2 Wire Leads			Blower	30 mm			75.7 mm				Ball							Plastic	Plastic	0.198 lb	89.81 g		70000 Hrs	75.7 mm
NMB TECHNOLOGIES BG0703-B045-000-00	70 °C	-10 °C	12 VDC	2 Wire Leads			Blower	30 mm			75.7 mm				Ball							Plastic	Plastic	0.198 lb	89.81 g		70000 Hrs	75.7 mm
NMB TECHNOLOGIES BG0703-B052-000-00	70 °C	-10 °C	24 VDC	2 Wire Leads	2200 RPM	29.5 dB(A)	Blower	30 mm	1.68 W	Square/Rounded	75.7 mm	75.7 mm	7.4 CFM	0.207 m³/min	Ball	49.8 Pa	0.2 in H2O		27.6 VDC	10 VDC	70 mA	Plastic	Plastic	0.198 lb	89.81 g
NMB TECHNOLOGIES 07530GA-24N-AA-00	70 °C	-40 C	24 VDC	2 Wire Leads	3650 RPM	43 dB	Blower	30 mm	4.8 W	Square/Rounded	75.7 mm	75.7 mm	13.1 CFM	0.367 mł/min	Ball	164.4 Pa	0.66 in H2O	Auto Restart	26.2 VDC	10 VDC	0.2 A	Plastic	Plastic				70000 Hrs		70 °C	-40 °C
