MP1907 Series

Catalog

100V, 2.5A, HIGH FREQUENCY, HALF-BRIDGE GATE DRIVERS

Part	Gate Type	Supplier Device Package	Package / Case	Current - Peak Output (Source, Sink) [custom]	Current - Peak Output (Source, Sink) [custom]	Mounting Type	Logic Voltage - VIL, VIH	Voltage - Supply [Max]	Voltage - Supply [Min]	High Side Voltage - Max (Bootstrap) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Input Type	Driven Configuration	Channel Type	Number of Drivers	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]
Monolithic Power Systems Inc. MP1907AGQ-Z	MOSFET (N-Channel) N-Channel MOSFET	10-QFN (3x3)	10-VFDFN Exposed Pad	2.5 A	2.5 A	Surface Mount	1 V 2.4 V	18 V	4.5 V	100 V	-40 C	125 °C	Non-Inverting	Half-Bridge	Independent	2	12 ns	9 ns
Monolithic Power Systems Inc. MP1907GQ-Z	MOSFET (N-Channel) N-Channel MOSFET	10-QFN (3x3)	10-VFDFN Exposed Pad	2.5 A	2.5 A	Surface Mount	1 V 2.4 V	18 V	4.5 V	100 V	-40 C	125 °C	Non-Inverting	Half-Bridge	Independent	2	12 ns	9 ns
Monolithic Power Systems Inc. MP1907GQ-P	MOSFET (N-Channel) N-Channel MOSFET	10-QFN (3x3)	10-VFDFN Exposed Pad	2.5 A	2.5 A	Surface Mount	1 V 2.4 V	18 V	4.5 V	100 V	-40 C	125 °C	Non-Inverting	Half-Bridge	Independent	2	12 ns	9 ns
Monolithic Power Systems Inc. MP1907AGQ-P	MOSFET (N-Channel) N-Channel MOSFET	10-QFN (3x3)	10-VFDFN Exposed Pad	2.5 A	2.5 A	Surface Mount	1 V 2.4 V	18 V	4.5 V	100 V	-40 C	125 °C	Non-Inverting	Half-Bridge	Independent	2	12 ns	9 ns
