RMCP2512F Series

Catalog

RES 38.3 OHM 1% 2W 2512

...

Part	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Tolerance	Number of Terminations [custom]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Features	Resistance	Composition	Temperature Coefficient	Supplier Device Package	Ratings	Power (Watts)
Stackpole Electronics Inc RMCP2512FT38R3	3.2 mm	6.3 mm	0.126 in	0.248 in	2512 (6432 Metric)	155 C	-55 C	1 %	2	0.03 "	0.75 mm	Automotive AEC-Q200	38.3 Ohms	Thick Film	100 ppm/°C	2512	AEC-Q200	2 W
Stackpole Electronics Inc RMCP2512FT86R6	3.2 mm	6.3 mm	0.126 in	0.248 in	2512 (6432 Metric)	155 C	-55 C	1 %	2	0.03 "	0.75 mm	Automotive AEC-Q200	86.6 Ohms	Thick Film	100 ppm/°C	2512	AEC-Q200	2 W
Stackpole Electronics Inc RMCP2512FT2R20	3.2 mm	6.3 mm	0.126 in	0.248 in	2512 (6432 Metric)	155 C	-55 C	1 %	2	0.03 "	0.75 mm	Automotive AEC-Q200	2.2 Ohms	Thick Film	200 ppm/°C	2512	AEC-Q200	2 W
Stackpole Electronics Inc RMCP2512FT316K	3.2 mm	6.3 mm	0.126 in	0.248 in	2512 (6432 Metric)	155 C	-55 C	1 %	2	0.03 "	0.75 mm	Automotive AEC-Q200	316 kOhms	Thick Film	100 ppm/°C	2512	AEC-Q200	2 W
Stackpole Electronics Inc RMCP2512FT665K	3.2 mm	6.3 mm	0.126 in	0.248 in	2512 (6432 Metric)	155 C	-55 C	1 %	2	0.03 "	0.75 mm	Automotive AEC-Q200	665 kOhms	Thick Film	100 ppm/°C	2512	AEC-Q200	2 W
Stackpole Electronics Inc RMCP2512FT10K5	3.2 mm	6.3 mm	0.126 in	0.248 in	2512 (6432 Metric)	155 C	-55 C	1 %	2	0.03 "	0.75 mm	Automotive AEC-Q200	10.5 kOhms	Thick Film	100 ppm/°C	2512	AEC-Q200	2 W
Stackpole Electronics Inc RMCP2512FT47R5	3.2 mm	6.3 mm	0.126 in	0.248 in	2512 (6432 Metric)	155 C	-55 C	1 %	2	0.03 "	0.75 mm	Automotive AEC-Q200	47.5 Ohms	Thick Film	100 ppm/°C	2512	AEC-Q200	2 W
Stackpole Electronics Inc RMCP2512FT604K	3.2 mm	6.3 mm	0.126 in	0.248 in	2512 (6432 Metric)	155 C	-55 C	1 %	2	0.03 "	0.75 mm	Automotive AEC-Q200	604 kOhms	Thick Film	100 ppm/°C	2512	AEC-Q200	2 W
Stackpole Electronics Inc RMCP2512FT105K	3.2 mm	6.3 mm	0.126 in	0.248 in	2512 (6432 Metric)	155 C	-55 C	1 %	2	0.03 "	0.75 mm	Automotive AEC-Q200	105 kOhms	Thick Film	100 ppm/°C	2512	AEC-Q200	2 W
Stackpole Electronics Inc RMCP2512FT2K94	3.2 mm	6.3 mm	0.126 in	0.248 in	2512 (6432 Metric)	155 C	-55 C	1 %	2	0.03 "	0.75 mm	Automotive AEC-Q200	2.94 kOhms	Thick Film	100 ppm/°C	2512	AEC-Q200	2 W
