807-046 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 46POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Gender | Contact Finish | Number of Positions/Bay/Row | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Color | Mounting Type | Card Type | Read Out | Contact Type | Termination | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Number of Rows [custom] | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Features | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Gold | 23 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Green | Right Angle Through Hole | Non Specified - Dual Edge | Single | Semi Bellows | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 46 | 2 | Copper Alloy | 125 °C | -40 C | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Tin | 23 | 3.96 mm | 0.156 in | Green | Board Edge Straddle Mount | Non Specified - Dual Edge | Dual | Semi Bellows | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 46 | 2 | Copper Alloy | 125 °C | -40 C | Card Extender | Flush Mount M3 Threaded Insert Top Opening | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Tin | 23 | 3.96 mm | 0.156 in | Green | Right Angle Through Hole | Non Specified - Dual Edge | Single | Semi Bellows | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 46 | 2 | Copper Alloy | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Gold | 23 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Green | Board Edge Straddle Mount | Non Specified - Dual Edge | Dual | Semi Bellows | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 46 | 2 | Copper Alloy | 125 °C | -40 C | Card Extender | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Gold | 23 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Green | Right Angle Through Hole | Non Specified - Dual Edge | Single | Semi Bellows | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 46 | 2 | Copper Alloy | 125 °C | -40 C | Flush Mount M3 Threaded Insert Top Opening | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Gold | 23 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Green | Through Hole | Non Specified - Dual Edge | Dual | Semi Bellows | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 46 | 2 | Copper Alloy | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Tin | 23 | 3.96 mm | 0.156 in | Green | Board Edge Straddle Mount | Non Specified - Dual Edge | Dual | Semi Bellows | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 46 | 2 | Copper Alloy | 125 °C | -40 C | Card Extender | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Gold | 23 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Green | Board Edge Straddle Mount | Non Specified - Dual Edge | Dual | Semi Bellows | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 46 | 2 | Copper Alloy | 125 °C | -40 C | Card Extender | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Gold | 23 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Green | Board Edge Straddle Mount | Non Specified - Dual Edge | Dual | Semi Bellows | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 46 | 2 | Copper Alloy | 125 °C | -40 C | Card Extender | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Gold | 23 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Green | Board Edge Straddle Mount | Non Specified - Dual Edge | Dual | Semi Bellows | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 46 | 2 | Copper Alloy | 125 °C | -40 C | Card Extender | 4-40 Flush Mount Threaded Insert Top Opening |
