1555 Series

Catalog

HOOK-UP WIRE 18AWG 16/30 PVC 1000FT SPOOL RED

Part	Voltage	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Strand [custom]	Conductor Strand [custom]	Length	Length	Operating Temperature [Max]	Operating Temperature [Min]	Qualification	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Wire Gauge	Jacket (Insulation) Material	Conductor Material	Jacket Color	Cable Type	Length [x]	Length [x]
ALPHA WIRE 1555 RD001	1 kV	0.41 mm	0.016 in	16	30 AWG	304.8 m	1000 ft	80 °C	-40 C	MIL-W-76B Type MW	2.01 mm	0.079 in	18 AWG	Poly-Vinyl Chloride (PVC)	Copper Tinned	Red	Hook-Up
ALPHA WIRE 1555 WN001	1 kV	0.41 mm	0.016 in	16	30 AWG	304.8 m	1000 ft	80 °C	-40 C	MIL-W-76B Type MW	2.01 mm	0.079 in	18 AWG	Poly-Vinyl Chloride (PVC)	Copper Tinned	White Brown Stripe	Hook-Up
ALPHA WIRE 1555 BR001	1 kV	0.41 mm	0.016 in	16	30 AWG	304.8 m	1000 ft	80 °C	-40 C	MIL-W-76B Type MW	2.01 mm	0.079 in	18 AWG	Poly-Vinyl Chloride (PVC)	Copper Tinned	Brown	Hook-Up
ALPHA WIRE 1555 WG001	1 kV	0.41 mm	0.016 in	16	30 AWG	304.8 m	1000 ft	80 °C	-40 C	MIL-W-76B Type MW	2.01 mm	0.079 in	18 AWG	Poly-Vinyl Chloride (PVC)	Copper Tinned		Hook-Up
ALPHA WIRE 1555 BL001	1 kV	0.41 mm	0.016 in	16	30 AWG	304.8 m	1000 ft	80 °C	-40 C	MIL-W-76B Type MW	2.01 mm	0.079 in	18 AWG	Poly-Vinyl Chloride (PVC)	Copper Tinned	Blue	Hook-Up
ALPHA WIRE 1555 VI005	1 kV	0.41 mm	0.016 in	16	30 AWG			80 °C	-40 C	MIL-W-76B Type MW	2.01 mm	0.079 in	18 AWG	Poly-Vinyl Chloride (PVC)	Copper Tinned	Violet	Hook-Up	100 ft	30.5 m
ALPHA WIRE 1555 OR001	1 kV	0.41 mm	0.016 in	16	30 AWG	304.8 m	1000 ft	80 °C	-40 C	MIL-W-76B Type MW	2.01 mm	0.079 in	18 AWG	Poly-Vinyl Chloride (PVC)	Copper Tinned	Orange	Hook-Up
ALPHA WIRE 1555 BR005	1 kV	0.41 mm	0.016 in	16	30 AWG			80 °C	-40 C	MIL-W-76B Type MW	2.01 mm	0.079 in	18 AWG	Poly-Vinyl Chloride (PVC)	Copper Tinned	Brown	Hook-Up	100 ft	30.5 m
ALPHA WIRE 1555 WS001	1 kV	0.41 mm	0.016 in	16	30 AWG	304.8 m	1000 ft	80 °C	-40 C	MIL-W-76B Type MW	2.01 mm	0.079 in	18 AWG	Poly-Vinyl Chloride (PVC)	Copper Tinned	White Gray Stripe	Hook-Up
ALPHA WIRE 1555 WR005	1 kV	0.41 mm	0.016 in	16	30 AWG			80 °C	-40 C	MIL-W-76B Type MW	2.01 mm	0.079 in	18 AWG	Poly-Vinyl Chloride (PVC)	Copper Tinned	White Red Stripe	Hook-Up	100 ft	30.5 m
