STM32C031F4 Series
Mainstream Arm Cortex-M0+ MCU with 16 Kbytes of Flash memory, 12 Kbytes RAM, 48 MHz CPU, 2x USART, timers, ADC, comm. I/F, 2-3.6V
Manufacturer: STMicroelectronics
Catalog
Mainstream Arm Cortex-M0+ MCU with 16 Kbytes of Flash memory, 12 Kbytes RAM, 48 MHz CPU, 2x USART, timers, ADC, comm. I/F, 2-3.6V
| Part | Supplier Device Package | Program Memory Type | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Speed | Peripherals | Oscillator Type | Number of I/O | Package / Case | Package / Case [y] | Package / Case [x] | Voltage - Supply (Vcc/Vdd) [Min] | Voltage - Supply (Vcc/Vdd) [Max] | Program Memory Size | Data Converters | Core Size | RAM Size | Core Processor | Connectivity |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 STMicroelectronics | 20-TSSOP | FLASH | 85 C | -40 ¯C | Surface Mount | 48 MHz | Brown-out Detect/Reset POR PWM Temp Sensor WDT | External Internal | 18 | 20-TSSOP | 4.4 mm | 0.173 " | 2 V | 3.6 V | 16 KB | A/D 15x12b SAR | 32-Bit | 12 K | ARM® Cortex®-M0+ | I2C IrDA LINbus SPI UART/USART |
Description
AI
The STM32C031x4/x6 mainstream microcontrollers are based on high-performance Arm®Cortex®-M0+ 32-bit RISC core operating at up to 48 MHz frequency. Offering a high level of integration, they are suitable for a wide range of applications in consumer, industrial and appliance domains and ready for the Internet of Things (IoT) solutions.
The devices incorporate a memory protection unit (MPU), high-speed embedded memories (12 Kbytes of SRAM and up to 32 Kbytes of flash program memory with read and write protection), DMA, an extensive range of system functions, enhanced I/Os, and peripherals. The devices offer standard communication interfaces (one I2Cs, one SPI / one I2S, and two USARTs), one 12-bit ADC (2.5 MSps) with up to 21 channels, a low-power RTC, an advanced control PWM timer, four general-purpose 16-bit timers, two watchdog timers, and a SysTick timer.
The devices operate within ambient temperatures from -40 to 125°C and with supply voltages from 2.0 V to 3.6 V. Optimized dynamic consumption combined with power-saving modes allows the design of low-power applications.
The devices are housed in packages with 20 to 48 pins.
