CFB600 Series

Isolated DC/DC Converters - Through Hole DC-DC Converter, Full Brick, 600 Watt, for Railway System, 43-160Vin, 28Vout, 88%, 10000F, Negative Logic

Manufacturer: Cincon Electronics Co. LTD

Catalog

Isolated DC/DC Converters - Through Hole DC-DC Converter, Full Brick, 600 Watt, for Railway System, 43-160Vin, 28Vout, 88%, 10000F, Negative Logic

Part	Supplier Device Package	Efficiency	Current - Output (Max) [Max]	Control Features	Voltage - Input (Min) [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Isolation	Type	Voltage - Input (Max) [Max]	Applications	Power (Watts)	Standard Number	Mounting Type	Approval Agency	Package / Case	Voltage - Output 1	Features	Number of Outputs	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]
Cincon Electronics Co. LTD CFB600-48S48	Full Brick	92 %	12.5 A	Active Low Enable	36 V	-40 °C	100 °C	1.5 kV	Isolated Module	75 V	ITE (Commercial)	600 W	60950-1	Through Hole	CE cURus	Full Brick	48 V	OCP OTP OVP Remote On/Off SCP UVLO	1	2.4 in	4.6 "	12.7 mm	0.5 in	61 mm	116.8 mm
Cincon Electronics Co. LTD CFB600-48S24	Full Brick	92 %	25 A	Active Low Enable	36 V	-40 °C	100 °C	1.5 kV	Isolated Module	75 V	ITE (Commercial)	600 W	60950-1	Through Hole	CE cURus	Full Brick	24 V	OCP OTP OVP Remote On/Off SCP UVLO	1	2.4 in	4.6 "	12.7 mm	0.5 in	61 mm	116.8 mm
Cincon Electronics Co. LTD CFB600-24S12P	Full Brick	88 %	50 A	Active High Enable	18 V	-40 °C	100 °C	1.5 kV	Isolated Module	36 V	ITE (Commercial)	600 W	60950-1	Through Hole	CE cURus	Full Brick	12 V	OCP OTP OVP Remote On/Off SCP UVLO	1	2.4 in	4.6 "	12.7 mm	0.5 in	61 mm	116.8 mm
Cincon Electronics Co. LTD CFB600-24S28P	Full Brick	90 %	21.5 A	Active High Enable	18 V	-40 °C	100 °C	1.5 kV	Isolated Module	36 V	ITE (Commercial)	602 W	60950-1	Through Hole	CE cURus	Full Brick	28 V	OCP OTP OVP Remote On/Off SCP UVLO	1	2.4 in	4.6 "	12.7 mm	0.5 in	61 mm	116.8 mm
Cincon Electronics Co. LTD CFB600W-110S48	Full Brick	88 %	12.5 A		43 V	-40 °C	100 °C	2250 VDC	Isolated Module	160 V	ITE (Commercial) Railway	600 W	50155 62368-1	Through Hole	CE cURus	Full Brick	48 V	OCP OTP OVP SCP UVLO	1	2.4 in	4.6 "	12.7 mm	0.5 in	61 mm	116.8 mm
Cincon Electronics Co. LTD CFB600-48S12P	Full Brick	90 %	50 A	Active High Enable	36 V	-40 °C	100 °C	1.5 kV	Isolated Module	75 V	ITE (Commercial)	600 W	60950-1	Through Hole	CE cURus	Full Brick	12 V	OCP OTP OVP Remote On/Off SCP UVLO	1	2.4 in	4.6 "	12.7 mm	0.5 in	61 mm	116.8 mm
Cincon Electronics Co. LTD CFB600-24S24P	Full Brick	89 %	25 A	Active High Enable	18 V	-40 °C	100 °C	1.5 kV	Isolated Module	36 V	ITE (Commercial)	600 W	60950-1	Through Hole	CE cURus	Full Brick	24 V	OCP OTP OVP Remote On/Off SCP UVLO	1	2.4 in	4.6 "	12.7 mm	0.5 in	61 mm	116.8 mm
Cincon Electronics Co. LTD CFB600-300S12N	Full Brick		50 A	Active Low Enable	180 V	-40 °C	100 °C	3000 V	Isolated Module	425 V	ITE (Commercial)	600 W	60950-1	Through Hole	CE cURus	Full Brick	12 V	OCP OTP OVP Remote On/Off SCP UVLO	1	2.4 in	4.6 "	12.7 mm	0.5 in	61 mm	116.8 mm
Cincon Electronics Co. LTD CFB700-48S28P	Full Brick	91 %	25 A	Active High Enable	36 V	-40 C	100 °C	1.5 kV	Isolated Module	75 V	ITE (Commercial)	700 W	60950-1	Through Hole	CE cURus	Full Brick	28 V	Remote On/Off	1	2.4 in	4.6 "	12.7 mm	0.5 in	61 mm	116.8 mm
Cincon Electronics Co. LTD CFB600-300S12	Full Brick		50 A	Active High Enable	180 V	-40 °C	100 °C	3000 V	Isolated Module	425 V	ITE (Commercial)	600 W	60950-1	Through Hole	CE cURus	Full Brick	12 V	OCP OTP OVP Remote On/Off SCP UVLO	1	2.4 in	4.6 "	12.7 mm	0.5 in	61 mm	116.8 mm
