M22-258 Series

Catalog

9+9 POS. MALE DIL VERTICAL THROUGHBOARD CONN. ROHS COMPLIANT: YES

Part	Insulation Height	Insulation Height	Fastening Type	Current Rating (Amps)	Pitch - Mating	Pitch - Mating	Number of Positions	Material Flammability Rating	Operating Temperature [Min]	Operating Temperature [Max]	Contact Length - Post [x]	Contact Length - Post	Number of Rows [custom]	Contact Shape	Row Spacing - Mating	Row Spacing - Mating	Mounting Type	Insulation Material	Number of Positions Loaded	Overall Contact Length	Overall Contact Length	Contact Finish - Post	Contact Type	Connector Type	Insulation Color	Contact Material	Shrouding	Contact Length - Mating	Contact Length - Mating	Termination	Style	Contact Finish - Mating
Harwin Inc. M22-2580946	0.059 in	1.5 mm	Push-Pull	1 A	0.079 "	2 mm	18	UL94 V-0	-40 C	105 ░C	0.091 "	2.3 mm	2	Square	2 mm	0.079 in	Through Hole	Nylon 6T Polyamide (PA6T)	All	8.8 mm	0.346 in	Tin	Male Pin	Header Cuttable	Black	Phosphor Bronze	Unshrouded	0.197 in	5 mm	Solder	Board to Board Cable
Harwin Inc. M22-2580305	0.059 in	1.5 mm	Push-Pull	1 A	0.079 "	2 mm	6	UL94 V-0	-40 C	105 ░C	0.091 "	2.3 mm	2	Square	2 mm	0.079 in	Through Hole	Nylon 6T Polyamide (PA6T)	All	8.8 mm	0.346 in		Male Pin	Header Cuttable	Black	Phosphor Bronze	Unshrouded	0.197 in	5 mm	Solder	Board to Board Cable	Gold
Harwin Inc. M22-2580405	0.059 in	1.5 mm	Push-Pull	1 A	0.079 "	2 mm	8	UL94 V-0	-40 C	105 ░C	0.091 "	2.3 mm	2	Square	2 mm	0.079 in	Through Hole	Nylon 6T Polyamide (PA6T)	All	8.8 mm	0.346 in		Male Pin	Header Cuttable	Black	Phosphor Bronze	Unshrouded	0.197 in	5 mm	Solder	Board to Board Cable	Gold
Harwin Inc. M22-2580805	0.059 in	1.5 mm	Push-Pull	1 A	0.079 "	2 mm	16	UL94 V-0	-40 C	105 ░C	0.091 "	2.3 mm	2	Square	2 mm	0.079 in	Through Hole	Nylon 6T Polyamide (PA6T)	All	8.8 mm	0.346 in		Male Pin	Header Cuttable	Black	Phosphor Bronze	Unshrouded	0.197 in	5 mm	Solder	Board to Board Cable	Gold
Harwin Inc. M22-2580546	0.059 in	1.5 mm	Push-Pull	1 A	0.079 "	2 mm	10	UL94 V-0	-40 C	105 ░C	0.091 "	2.3 mm	2	Square	2 mm	0.079 in	Through Hole	Nylon 6T Polyamide (PA6T)	All	8.8 mm	0.346 in	Tin	Male Pin	Header Cuttable	Black	Phosphor Bronze	Unshrouded	0.197 in	5 mm	Solder	Board to Board Cable
