E2104S Series
Manufacturer: Prysmian Group
Beta
⌘K
CABLE 4COND 22AWG ORANGE SHLD
| Part | Cable Type | Jacket (Insulation) Material | Shield Material | Shield Type | Number of Conductors | Conductor Material | Jacket (Insulation) Thickness [x] | Jacket (Insulation) Thickness [x] | Conductor Strand [custom] | Conductor Strand [custom] | Jacket Color | Conductor Insulation | Wire Gauge | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Operating Temperature [Max] | Operating Temperature [Min] | Voltage | Length | Length | Shield Coverage | Features | Usage | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Prysmian Group | Multi-Conductor | Plenum Poly-Vinyl Chloride (PVC) | Flexfoil® | Foil | 4 | Copper Bare | 0.381 mm | 0.015 in | 30 AWG | 7 | Orange | Poly-Vinyl Chloride (PVC) | 22 AWG | 3.73 mm | 0.147 " | 75 ░C | 0 °C | 300 VDC | 304.8 m | 1000 ft | 100 % | Drain Wire | |||
 Prysmian Group | Multi-Conductor | Plenum Poly-Vinyl Chloride (PVC) | Flexfoil® | Foil | 4 | Copper Bare | 0.381 mm | 0.015 in | 30 AWG | 7 | Natural | Poly-Vinyl Chloride (PVC) | 22 AWG | 3.73 mm | 0.147 " | 75 ░C | 0 °C | 300 VDC | 152.4 m | 500 ft | 100 % | Drain Wire | Alarm Security Sound | ||
Prysmian Group | Multi-Conductor | Plenum Poly-Vinyl Chloride (PVC) | Foil | 4 | Copper Bare | 0.381 mm | 0.015 in | 30 AWG | 7 | White | Poly-Vinyl Chloride (PVC) | 22 AWG | 3.73 mm | 0.147 " | 75 ░C | 0 °C | 300 VDC | 15.24 m 304.8 m | 50 ft 1000 ft | Drain Wire | Alarm Security Sound | 25 ft 100 ft | 7.62 m 30.5 m | ||
Prysmian Group | Multi-Conductor | Plenum Poly-Vinyl Chloride (PVC) | Foil | 4 | Copper Bare | 0.381 mm | 0.015 in | 30 AWG | 7 | Natural | Poly-Vinyl Chloride (PVC) | 22 AWG | 3.73 mm | 0.147 " | 75 ░C | 0 °C | 300 VDC | 152.4 m | 500 ft | Drain Wire | Alarm Security Sound | ||||
Prysmian Group | Multi-Conductor | Plenum Poly-Vinyl Chloride (PVC) | Foil | 4 | Copper Bare | 0.381 mm | 0.015 in | 30 AWG | 7 | Natural | Poly-Vinyl Chloride (PVC) | 22 AWG | 3.73 mm | 0.147 " | 75 ░C | 0 °C | 300 VDC | 15.24 m 304.8 m | 50 ft 1000 ft | Drain Wire | Alarm Security Sound | 25 ft 100 ft | 7.62 m 30.5 m | ||
Prysmian Group | Multi-Conductor | Plenum Poly-Vinyl Chloride (PVC) | Foil | 4 | Copper Bare | 0.381 mm | 0.015 in | 30 AWG | 7 | Natural | Poly-Vinyl Chloride (PVC) | 22 AWG | 3.73 mm | 0.147 " | 75 ░C | 0 °C | 300 VDC | 304.8 m | 1000 ft | Drain Wire | Alarm Security Sound | ||||
Prysmian Group | Multi-Conductor | Plenum Poly-Vinyl Chloride (PVC) | Foil | 4 | Copper Bare | 0.381 mm | 0.015 in | 30 AWG | 7 | Orange | Poly-Vinyl Chloride (PVC) | 22 AWG | 3.73 mm | 0.147 " | 75 ░C | 0 °C | 300 VDC | 304.8 m | 1000 ft | Drain Wire | |||||
Prysmian Group | Multi-Conductor | Plenum Poly-Vinyl Chloride (PVC) | Flexfoil® | Foil | 4 | Copper Bare | 0.381 mm | 0.015 in | 30 AWG | 7 | Natural | Poly-Vinyl Chloride (PVC) | 22 AWG | 3.73 mm | 0.147 " | 75 ░C | 0 °C | 300 VDC | 15.24 m 304.8 m | 50 ft 1000 ft | 100 % | Drain Wire | Alarm Security Sound | 25 ft 100 ft | 7.62 m 30.5 m |
Prysmian Group | Multi-Conductor | Plenum Poly-Vinyl Chloride (PVC) | Flexfoil® | Foil | 4 | Copper Bare | 0.381 mm | 0.015 in | 30 AWG | 7 | Natural | Poly-Vinyl Chloride (PVC) | 22 AWG | 3.73 mm | 0.147 " | 75 ░C | 0 °C | 300 VDC | 152.4 m 304.8 m | 500 ft 1000 ft | 100 % | Drain Wire | Alarm Security Sound | 100 ft | 30.5 m |
Prysmian Group | Multi-Conductor | Plenum Poly-Vinyl Chloride (PVC) | Flexfoil® FlexfoilÛ | Foil | 4 | Copper Bare | 0.381 mm | 0.015 in | 30 AWG | 7 | White | Poly-Vinyl Chloride (PVC) | 22 AWG | 3.73 mm | 0.147 " | 75 ░C | 0 °C | 300 VDC | 15.24 m 304.8 m | 50 ft 1000 ft | 100 % | Drain Wire | Alarm Security Sound | 25 ft 100 ft | 7.62 m 30.5 m |
