AM2S Series

Manufacturer: aimtec

Catalog

DC DC CONVERTER 15V 2W

Part	Number of Outputs	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Applications	Voltage - Input (Min) [Min]	Efficiency	Voltage - Isolation	Type	Voltage - Input (Max) [Max]	Current - Output (Max) [Max]	Power (Watts)	Operating Temperature [Max]	Operating Temperature [Min]	Approval Agency	Voltage - Output 1	Mounting Type	Package / Case
aimtec AM2S-2415SH30Z	1	7.5 mm	0.3 "	0.4 "	10.2 mm	0.46 in	11.7 mm	ITE (Commercial)	21.6 V	86 %	3000 V	Isolated Module	26.4 V	133 mA	2 W	85 °C	-40 C	CE	15 V	Through Hole	4-SIP Module
aimtec AM2S-0524SZ	1	7.5 mm	0.3 "	0.4 "	10.2 mm	0.46 in	11.7 mm	ITE (Commercial)	4.5 V	86 %	1000 V	Isolated Module	5.5 V	83 mA	2 W	85 °C	-40 C	CE	24 V	Through Hole	4-SIP Module
aimtec AM2S-1212SZ	1	7.5 mm	0.29 in	0.4 "	10.2 mm	0.46 in	11.7 mm	ITE (Commercial)	10.8 V	85 %	1000 V	Isolated Module	13.2 V	167 mA	2 W	85 °C	-40 C	CE	12 V	Through Hole	4-SIP Module
aimtec AM2S-2409SH30Z	1	7.5 mm	0.3 "	0.4 "	10.2 mm	0.46 in	11.7 mm	ITE (Commercial)	21.6 V	85 %	3000 V	Isolated Module	26.4 V	222 mA	2 W	85 °C	-40 C	CE	9 V	Through Hole	4-SIP Module
aimtec AM2S-1205SH30Z	1	7.5 mm	0.29 in	0.4 "	10.2 mm	0.46 in	11.7 mm	ITE (Commercial)	10.8 V	81 %	3000 V	Isolated Module	13.2 V	400 mA	2 W	85 °C	-40 C	CE	5 V	Through Hole	4-SIP Module
aimtec AM2S-2403SH30Z	1	7.5 mm	0.29 in	0.4 "	10.2 mm	0.46 in	11.7 mm	ITE (Commercial)	21.6 V	81 %	3000 V	Isolated Module	26.4 V	400 mA	2 W	85 °C	-40 C	CE	3.3 V	Through Hole	4-SIP Module
aimtec AM2S-2415SZ	1	7.5 mm	0.3 "	0.4 "	10.2 mm	0.46 in	11.7 mm	ITE (Commercial)	21.6 V	86 %	1000 V	Isolated Module	26.4 V	133 mA	2 W	85 °C	-40 C	CE	15 V	Through Hole	4-SIP Module
aimtec AM2S-1218SZ	1	7.5 mm	0.3 "	0.4 "	10.2 mm	0.46 in	11.7 mm	ITE (Commercial)	10.8 V	84 %	1000 V	Isolated Module	13.2 V	111 mA	2 W	85 °C	-40 C	CE	18 V	Through Hole	4-SIP Module
aimtec AM2S-2424SZ	1	7.5 mm	0.3 "	0.4 "	10.2 mm	0.46 in	11.7 mm	ITE (Commercial)	21.6 V	88 %	1000 V	Isolated Module	26.4 V	83 mA	2 W	85 °C	-40 C	CE	24 V	Through Hole	4-SIP Module
aimtec AM2S-0518SZ	1	7.5 mm	0.29 in	0.4 "	10.2 mm	0.46 in	11.7 mm	ITE (Commercial)	4.5 V	80 %	1000 V	Isolated Module	5.5 V	111 mA	2 W	85 °C	-40 C	CE	18 V	Through Hole	4-SIP Module
