SI5459 Series
Manufacturer: Vishay General Semiconductor - Diodes Division
Beta
⌘K
MOSFET P-CH 20V 8A PPAK
| Part | Mounting Type | Vgs (Max) | Rds On (Max) @ Id, Vgs [Max] | Drive Voltage (Max Rds On, Min Rds On) | Package / Case | Power Dissipation (Max) | Vgs(th) (Max) @ Id | Input Capacitance (Ciss) (Max) @ Vds | Supplier Device Package | Operating Temperature [Max] | Operating Temperature [Min] | FET Type | Drain to Source Voltage (Vdss) | Gate Charge (Qg) (Max) @ Vgs [Max] | Technology | Current - Continuous Drain (Id) @ 25°C |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Vishay General Semiconductor - Diodes Division | Surface Mount | 12 V | 52 mOhm | 2.5 V 4.5 V | PowerPAK® ChipFET™ Single | 3.5 W 10.9 W | 1.4 V | 665 pF | PowerPAK® ChipFET™ Single | 150 °C | -50 °C | P-Channel | 20 V | 26 nC | MOSFET (Metal Oxide) | 8 A |
