DSA1103 Series

Catalog

MEMS OSCILLATOR, AUTOMOTIVE, LOW

Part	Frequency Stability	Base Resonator	Current - Supply (Disable) (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Ratings	Function	Current - Supply (Max) [Max]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Package / Case	Voltage - Supply [Max]	Voltage - Supply [Min]	Output	Mounting Type	Frequency	Type	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]
Microchip Technology DSA1103CI1-125.0000VAO	50 ppm	MEMS	95 µA	85 °C	-40 °C	AEC-Q100	Standby (Power Down)	32 mA	0.035 "	0.9 mm	6-VDFN	3.6 V	2.25 V	LVDS	Surface Mount	125 MHz	XO (Standard)	3.2 mm	2.5 mm	0.126 in	0.098 in
Microchip Technology DSA1103DL1-125.0000VAO	50 ppm	MEMS	95 µA	105 ░C	-40 °C	AEC-Q100	Standby (Power Down)	32 mA	0.035 "	0.9 mm	6-VDFN	3.63 V	2.25 V	LVDS	Surface Mount	125 MHz	SO (SAW)	2.5 mm	2 mm	0.098 "	0.079 in
Microchip Technology DSA1103CA2-020.0000VAO	25 ppm	MEMS	95 µA	125 °C	-40 °C	AEC-Q100	Standby (Power Down)	32 mA	0.035 "	0.9 mm	6-VDFN	3.6 V	2.25 V	LVDS	Surface Mount	20 MHz	XO (Standard)	3.2 mm	2.5 mm	0.126 in	0.098 in
