AM30C Series
Manufacturer: aimtec
Beta
⌘K
DC DC CONVERTER 15V 30W
| Part | Applications | Efficiency | Standard Number | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Input (Min) [Min] | Voltage - Input (Max) [Max] | Mounting Type | Number of Outputs | Power (Watts) | Approval Agency | Features | Current - Output (Max) [Max] | Voltage - Output 1 | Voltage - Isolation | Package / Case | Type | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 aimtec | ITE (Commercial) | 88 % | 62368-1 | 85 °C | -40 C | 18 V | 75 V | Through Hole | 1 | 30 Watts | CE | Adjustable Output Remote On/Off | 2 A | 15 V | 1.5 kV | 6-DIP Module | Isolated Module | 1 " | 25.4 mm | 1 in | 0.46 in | 11.7 mm | 25.4 mm |
