HA16PA Series
Manufacturer: Hirose Electric Co Ltd
Beta
⌘K
CONN PLUG FMALE 3P SOLDER EYELET
| Part | Shielding | Color | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Shell Size - Insert | Current Rating (Amps) | Material Flammability Rating | Backshell Material, Plating | Insert Material [custom] | Insert Material [custom] | Connector Type | Orientation | Operating Temperature [Min] | Operating Temperature [Max] | Features | Voltage Rating | Contact Material | Mounting Type | Shell Material | Fastening Type | Contact Finish - Mating | Primary Material | Termination | Cable Opening | Cable Opening | Applications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Hirose Electric Co Ltd | Shielded | Black Silver | 78.7 µin | 2 µm | 16 | 15 A | UL94 V-0 | Nickel Zinc Alloy | Nylon | Polyamide (PA) | Plug Female Sockets | Keyed | -25 °C | 70 °C | Backshell | 130 VAC 180 VDC | Phosphor Bronze | Free Hanging (In-Line) | Stainless Steel | Latch Lock | Silver | Metal | Solder Eyelet(s) | 0.48 in | 12.2 mm | Industrial |
