APTGT400DA60D3G-Module Series

650V/Three level inverter/IGBT modules

Catalog

650V/Three level inverter/IGBT modules

Part	Configuration	Input	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Power - Max [Max]	Supplier Device Package	Vce(on) (Max) @ Vge, Ic	IGBT Type	Package / Case	Current - Collector Cutoff (Max) [Max]	Current - Collector (Ic) (Max) [Max]	Voltage - Collector Emitter Breakdown (Max) [Max]	Input Capacitance (Cies) @ Vce	Voltage - Collector Emitter Breakdown (Max)
Microchip Technology APTGT400A120D3G	Half Bridge	Standard	Chassis Mount	150 °C	-40 °C	2100 W	D3	2.1 V	Trench Field Stop	D-3 Module	750 µA	580 A	1200 V
Microchip Technology APTGT400A120G	Half Bridge	Standard	Chassis Mount	150 °C	-40 °C	1785 W	SP6	2.1 V	Trench Field Stop	SP6	750 µA		1200 V	28 nF
Microchip Technology APTGT400TL65G
Microchip Technology APTGT400A60D3G	Half Bridge	Standard	Chassis Mount	175 °C	-40 C	1250 W	D3	1.9 V	Trench Field Stop	D-3 Module	500 çA	500 A	600 V
Microchip Technology APTGT400DA60D3G	Single	Standard	Chassis Mount	175 °C	-40 C	1250 W	D3	1.9 V	Trench Field Stop	D-3 Module	500 çA	500 A	600 V
Microchip Technology APTGT400DA120G	Single	Standard	Chassis Mount	150 °C	-40 °C	1785 W	SP6	2.1 V	Trench Field Stop	SP6	750 µA		1200 V	28 nF
Microchip Technology APTGT400U170D4G	Single	Standard	Chassis Mount			2080 W	D4	2.4 V	Trench Field Stop	D4	1 mA	800 A		33 nF	1700 V

650V/Three level inverter/IGBT modules

• + Configuration: Three level inverter

• + VCES (V): 650

• + VCESat (V): 1.5

• + Current (A) Tc=80C: 400

• + Silicon type: TRENCH 3 IGBT

• + Package: SP6C
