A3-14DA Series

Catalog

CONN RCPT 14POS 0.079 GOLD SMD

Part	Applications	Contact Material	Contact Shape	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Insulation Material	Number of Rows [custom]	Contact Type	Material Flammability Rating	Insulation Color	Contact Finish - Mating	Operating Temperature [Min]	Operating Temperature [Max]	Number of Positions	Voltage Rating	Pitch - Mating	Pitch - Mating	Mated Stacking Heights	Mounting Type	Termination	Insulation Height	Insulation Height	Fastening Type	Contact Finish - Post	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Positions Loaded	Row Spacing - Mating	Row Spacing - Mating	Style	Connector Type
Hirose Electric Co Ltd A3-14DA-2SV(71)	General Purpose Telecommunications	Phosphor Bronze	Square	39.4 çin	1 çm	Polyphenylene Sulfide (PPS)	2	Female Socket	UL94 V-0	Brown	Gold	-55 C	85 °C	14	200 VAC	0.079 "	2 mm	5.1 mm 6 mm	Surface Mount	Solder	0.165 in	4.2 mm	Push-Pull	Tin	8 µin	0.203 µm	All	2 mm	0.079 in	Board to Board Cable	Receptacle
Hirose Electric Co Ltd A3-14DA-2SV	General Purpose Telecommunications	Phosphor Bronze	Square	39.4 çin	1 çm	Polyphenylene Sulfide (PPS)	2	Female Socket	UL94 V-0	Brown	Gold	-55 C	85 °C	14	200 VAC	0.079 "	2 mm	5.1 mm 6 mm	Surface Mount	Solder	0.165 in	4.2 mm	Push-Pull	Tin	8 µin	0.203 µm	All	2 mm	0.079 in	Board to Board Cable	Receptacle
