MCP6041 Series

600 nA, Rail-to-Rail Input/Output Op Amps

Catalog

600 nA, Rail-to-Rail Input/Output Op Amps

Part	Gain Bandwidth Product	Amplifier Type	Package / Case	Current - Supply	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Input Offset	Voltage - Supply Span (Max) [Max]	Mounting Type	Voltage - Supply Span (Min) [Min]	Supplier Device Package	Current - Output / Channel	Output Type	Slew Rate	Current - Input Bias	Number of Circuits	Package / Case [y]	Package / Case [x]	Package / Case [custom]	Package / Case	Package / Case	Qualification	Grade
Microchip Technology MCP6041T-E/OT	14 kHz	General Purpose	SC-74A SOT-753	600 nA	125 °C	-40 °C	3 mV	6 V	Surface Mount	1.4 V	SOT-23-5	20 mA	Rail-to-Rail	0.003 V/µs	1 pA	1
Microchip Technology MCP6041-E/SN	14 kHz	General Purpose	8-SOIC	600 nA	125 °C	-40 °C	3 mV	6 V	Surface Mount	1.4 V	8-SOIC		Rail-to-Rail	0.003 V/µs	1 pA	1	3.9 mm	0.154 in
Microchip Technology MCP6041T-I/OT	14 kHz	General Purpose	SC-74A SOT-753	600 nA	85 °C	-40 °C	3 mV	6 V	Surface Mount	1.4 V	SOT-23-5	20 mA	Rail-to-Rail	0.003 V/µs	1 pA	1
Microchip Technology MCP6041T-E/MS	14 kHz	General Purpose	8-MSOP 8-TSSOP	600 nA	125 °C	-40 °C	3 mV	6 V	Surface Mount	1.4 V	8-MSOP		Rail-to-Rail	0.003 V/µs	1 pA	1			0.118 in	3 mm
Microchip Technology MCP6041-I/SN	14 kHz	General Purpose	8-SOIC	600 nA	85 °C	-40 °C	3 mV	6 V	Surface Mount	1.4 V	8-SOIC	20 mA	Rail-to-Rail	0.003 V/µs	1 pA	1	3.9 mm	0.154 in
Microchip Technology MCP6041-E/MS	14 kHz	General Purpose	8-MSOP 8-TSSOP	600 nA	125 °C	-40 °C	3 mV	6 V	Surface Mount	1.4 V	8-MSOP		Rail-to-Rail	0.003 V/µs	1 pA	1			0.118 in	3 mm
Microchip Technology MCP6041-I/P	14 kHz	General Purpose	8-DIP	600 nA	85 °C	-40 °C	3 mV	6 V	Through Hole	1.4 V	8-PDIP	20 mA	Rail-to-Rail	0.003 V/µs	1 pA	1				0.3 in	7.62 mm
Microchip Technology MCP6041T-I/MS	14 kHz	General Purpose	8-MSOP 8-TSSOP	600 nA	85 °C	-40 °C	3 mV	6 V	Surface Mount	1.4 V	8-MSOP	20 mA	Rail-to-Rail	0.003 V/µs	1 pA	1			0.118 in	3 mm
Microchip Technology MCP6041-E/P	14 kHz	General Purpose	8-DIP	600 nA	125 °C	-40 °C	3 mV	6 V	Through Hole	1.4 V	8-PDIP		Rail-to-Rail	0.003 V/µs	1 pA	1				0.3 in	7.62 mm
Microchip Technology MCP6041-E/SNVAO	14 kHz	General Purpose	8-SOIC	600 nA	125 °C	-40 °C	3 mV	6 V	Surface Mount	1.4 V	8-SOIC		Rail-to-Rail	0.003 V/µs	1 pA	1	3.9 mm	0.154 in				AEC-Q100	Automotive

Catalog

600 nA, Rail-to-Rail Input/Output Op Amps

Key Features

• * Low Quiescent Current: 600 nA/amplifier (typical)

• * Rail-to-Rail Input/Output

• * Gain Bandwidth Product: 14 kHz (typical)

• * Wide Supply Voltage Range: 1.4V to 6.0V

• * Unity Gain Stable

• * Available in Single, Dual, and Quad

• * Chip Select (CS) with MCP6043

• * Available in 5-lead and 6-lead SOT-23 Packages

Description

The MCP6041 operational amplifier (op amp) has a gain bandwidth product of 14 kHz with a low typical operating current of 600 nA and an offset voltage that is less than 3 mV. The MCP6041 uses Microchip's advanced CMOS technology, which provides low bias current, high-speed operation, high open-loop gain and rail-to-rail output swing. The MCP6041 operates with a single supply voltage that can be as low as 1.4V, while drawing less than 1.0 uA of quiescent current. The MCP6041 is available in standard 8-lead PDIP, SOIC and MSOP packages. This amplifier is ideal for industrial process control, low-power battery-operated devices, portable equipment and wearable products.
