2SCR586 Series

NPN, TO-263AB, 80V 5A, Power Transistor for Automotive

Catalog

NPN, TO-263AB, 80V 5A, Power Transistor for Automotive

Part	Current - Collector Cutoff (Max) [Max]	Operating Temperature	DC Current Gain (hFE) (Min) @ Ic, Vce [Min]	Power - Max [Max]	Transistor Type	Mounting Type	Voltage - Collector Emitter Breakdown (Max) [Max]	Package / Case	Current - Collector (Ic) (Max) [Max]	Supplier Device Package	Vce Saturation (Max) @ Ib, Ic	Frequency - Transition	Grade	Qualification
Rohm Semiconductor 2SCR586D3TL1	1 µA 1 µA	150 °C	120	10 W	NPN	Surface Mount	80 V	DPAK (2 Leads + Tab) SC-63 TO-252-3	5 A	TO-252	300 mV	200 MHz
Rohm Semiconductor 2SCR586JFRGTLL	1 µA	150 °C	120	40 W	NPN	Surface Mount	80 V	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	5 A		300 mV	200 MHz	Automotive	AEC-Q101
Rohm Semiconductor 2SCR586D3FRATL	1 µA	150 °C	120	10 W	NPN	Surface Mount	80 V	DPAK (2 Leads + Tab) SC-63 TO-252-3	5 A	TO-252	300 mV	200 MHz	Automotive	AEC-Q101

NPN, TO-263AB, 80V 5A, Power Transistor for Automotive

2SCR586JFRG is a power transistor with Low VCE(sat), suitable for low frequency amplifier.
