887-020 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 20POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Contact Material | Mounting Type | Card Type | Termination | Number of Positions/Bay/Row | Pitch | Pitch | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature | Contact Type | Number of Positions | Number of Rows [custom] | Contact Finish | Gender | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Color | Read Out | Termination Rows | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Copper Alloy | Right Angle Through Hole | Non Specified - Dual Edge | Solder | 10 | 3.96 mm | 0.156 in | 125 °C | -40 C | 4-40 Flush Mount Threaded Insert Top Opening | Cantilever | 20 | 2 | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Black | Dual | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Copper Alloy | Through Hole | Non Specified - Single Edge | Wire Wrap | 20 Bay/Row | 3.96 mm | 0.156 in | 125 °C | -40 C | M3 Threaded Insert Top Mount Opening | Cantilever | 20 | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Black | Single | 1 | 1 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Copper Alloy | Through Hole | Non Specified - Single Edge | Wire Wrap | 20 Bay/Row | 3.96 mm | 0.156 in | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | Cantilever | 20 | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Black | Single | 1 | 1 | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Copper Alloy | Through Hole | Non Specified - Dual Edge | Wire Wrap | 10 | 3.96 mm | 0.156 in | 125 °C | -40 C | Floating Bobbin Top Mount Opening | Cantilever | 20 | 2 | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Black | Dual | 0.116 " | 2.95 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Copper Alloy | Board Edge Straddle Mount | Non Specified - Dual Edge | Solder | 10 | 3.96 mm | 0.156 in | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | Cantilever | 20 | 2 | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Black | Dual | 0.156 " | 3.96 mm | Card Extender | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Copper Alloy | Right Angle Through Hole | Non Specified - Dual Edge | Solder | 10 | 3.96 mm | 0.156 in | 125 °C | -40 C | Side Mount Opening Unthreaded | Cantilever | 20 | 2 | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Black | Dual | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Copper Alloy | Through Hole | Non Specified - Single Edge | Wire Wrap | 20 Bay/Row | 3.96 mm | 0.156 in | 125 °C | -40 C | Cantilever | 20 | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Black | Single | 1 | 1 | 0.128 " | 3.25 mm | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Copper Alloy | Through Hole | Non Specified - Single Edge | Solder Eyelet(s) | 20 Bay/Row | 3.96 mm | 0.156 in | 125 °C | -40 C | Flush Mount Side Opening Unthreaded | Cantilever | 20 | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Black | Single | 1 | 1 | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Copper Alloy | Right Angle Through Hole | Non Specified - Single Edge | Solder | 20 Bay/Row | 3.96 mm | 0.156 in | 125 °C | -40 C | Cantilever | 20 | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Black | Single | 1 | 1 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Copper Alloy | Through Hole | Non Specified - Dual Edge | Wire Wrap | 10 | 3.96 mm | 0.156 in | 125 °C | -40 C | M3 Threaded Insert Top Mount Opening | Cantilever | 20 | 2 | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Black | Dual |
