Nch 30V 13.5A Middle Power MOSFET
Description
AI
RS3E135BN is low on-resistance and small surface mount package MOSFET for switching application.
Beta
⌘K
Nch 30V 13.5A Middle Power MOSFET
Nch 30V 13.5A Middle Power MOSFET
| Part | Mounting Type | Drain to Source Voltage (Vdss) | Package / Case | Package / Case | Package / Case | Supplier Device Package | Vgs(th) (Max) @ Id | Drive Voltage (Max Rds On, Min Rds On) | Gate Charge (Qg) (Max) @ Vgs | Operating Temperature [Max] | Operating Temperature [Min] | Input Capacitance (Ciss) (Max) @ Vds [Max] | Current - Continuous Drain (Id) @ 25°C | Rds On (Max) @ Id, Vgs | Power Dissipation (Max) | FET Type | Technology | Vgs (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | Surface Mount | 30 V | 0.154 in | 8-SOIC | 3.9 mm | 8-SOP | 2.5 V | 10 V | 8.3 nC | 150 °C | -55 °C | 680 pF | 9.5 A | 14.6 mOhm | 2 W | N-Channel | MOSFET (Metal Oxide) | 20 V |
