846-056 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 56POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Number of Positions/Bay/Row | Number of Positions | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Contact Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Termination | Color | Contact Finish | Number of Rows [custom] | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Features | Card Type | Read Out | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Pitch | Pitch |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 28 | 56 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Solder | Green | Gold | 2 | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Card Extender | Non Specified - Dual Edge | Dual | 125 °C | -40 C | Female | 3.18 mm | 0.125 in |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 28 | 56 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Solder | Green | Gold | 2 | Through Hole | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Dual | 125 °C | -40 C | Female | 3.18 mm | 0.125 in | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 28 | 56 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Solder | Green | Gold | 2 | Right Angle Through Hole | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Dual | 125 °C | -40 C | Female | 3.18 mm | 0.125 in | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 28 | 56 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Solder | Green | Gold | 2 | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Card Extender | Non Specified - Dual Edge | Dual | 125 °C | -40 C | Female | 3.18 mm | 0.125 in | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 28 | 56 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 0.156 " | 3.96 mm | Solder Eyelet(s) | Green | Gold | 2 | Through Hole | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Dual | 125 °C | -40 C | Female | 3.18 mm | 0.125 in | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 28 | 56 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 0.156 " | 3.96 mm | Solder | Green | Gold | 2 | Right Angle Through Hole | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Dual | 125 °C | -40 C | Female | 3.18 mm | 0.125 in | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 28 | 56 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Wire Wrap | Green | Gold | 2 | Through Hole | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Dual | 125 °C | -40 C | Female | 3.18 mm | 0.125 in | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 28 | 56 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Solder | Green | Gold | 2 | Through Hole | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Dual | 125 °C | -40 C | Female | 3.18 mm | 0.125 in | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 28 | 56 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Flush Mount M3 Threaded Insert Top Opening | Solder Eyelet(s) | Green | Gold | 2 | Through Hole | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Dual | 125 °C | -40 C | Female | 3.18 mm | 0.125 in | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 28 | 56 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | Solder Eyelet(s) | Green | Gold | 2 | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Card Extender | Non Specified - Dual Edge | Dual | 125 °C | -40 C | Female | 3.18 mm | 0.125 in |
