Medium Power Amplifier Chip, 21 - 32 GHz
Key Features
• Output IP3: +33 dBm
• P1dB: +24 dBm
• Gain: 16 dB
• Supply Voltage: +5V
• 50 Ohm Matched Input/Output
• Die Size: 2.04 x 1.09 x 0.1 mm
Description
AI
The HMC499 is a high dynamic range GaAs PHEMT MMIC Medium Power Amplifier which operates between 21 and 32 GHz. The HMC499 provides 16 dB of gain, and an output power of +24 dBm at 1 dB compression from a +5V supply voltage. The HMC499 amplifier can easily be integrated into Multi-Chip-Modules (MCMs) due to its small size. All data is with the chip in a 50 Ohm test fixture connected via 0.025mm (1 mil) diameter wire bonds of minimal length 0.31mm (12 mils).ApplicationsPoint-to-Point RadiosPoint-to-Multi-Point RadiosVSATMilitary & Space
