GaAs pHEMT MMIC Low Noise Amplifier, 7.5 - 26.5 GHz
Key Features
• Low Noise Figure: 2.5 dB
• Gain: 13 dB
• P1dB Output Power: 13 dBm
• Single Supply Voltage: +3.5V @ 70mA
• Output IP3: +23 dBm
• 50 Ohm matched Input/Output
• 24 Lead 4x4 mm SMT Package: 16mm2
Description
AI
The HMC962LC4 is a self-biased GaAs MMI C Low Noise Amplifier housed in a leadless 4x4 mm ceramic surface mount package. The amplifier operates between 7.5 and 26.5 GHz, providing 13 dB of small signal gain, 2.5 dB noise figure, and output IP 3 of +23 dBm, while requiring only 70 mA from a +3.5 V supply. The P1dB output power of +13 dBm enables the LNA to function as a LO driver for balanced, I/Q or image reject mixers. The HMC962LC4 also features I/Os that are DC blocked and internally matched to 50 Ohms, making it ideal for high capacity microwave radios and VSAT applications.ApplicationsPoint-to-Point RadiosPoint-to-Multi-Point RadiosMilitary & SpaceTest Instrumentation
