846-035 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 35POS 0.125
| Part | Material - Insulation | Termination Rows | Termination | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Read Out | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Contact Type | Card Type | Mounting Type | Gender | Pitch | Pitch | Number of Positions | Color | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Wire Wrap | Copper Alloy | 125 °C | -40 C | 35 | 0.25 Ám | 10 Áin | 1 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Cantilever | Non Specified - Single Edge | Through Hole | Female | 3.18 mm | 0.125 in | 35 | Green | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Solder | Copper Alloy | 125 °C | -40 C | 35 | 0.25 Ám | 10 Áin | 1 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Cantilever | Non Specified - Single Edge | Through Hole | Female | 3.18 mm | 0.125 in | 35 | Green | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Solder | Copper Alloy | 125 °C | -40 C | 35 | 0.25 Ám | 10 Áin | 1 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Cantilever | Non Specified - Single Edge | Right Angle Through Hole | Female | 3.18 mm | 0.125 in | 35 | Green | 4-40 Flush Mount Threaded Insert Top Opening | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Solder | Copper Alloy | 125 °C | -40 C | 35 | 0.25 Ám | 10 Áin | 1 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Cantilever | Non Specified - Single Edge | Right Angle Through Hole | Female | 3.18 mm | 0.125 in | 35 | Green | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Wire Wrap | Copper Alloy | 125 °C | -40 C | 35 | 0.25 Ám | 10 Áin | 1 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Cantilever | Non Specified - Single Edge | Through Hole | Female | 3.18 mm | 0.125 in | 35 | Green | 4-40 Flush Mount Threaded Insert Top Opening | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Solder | Copper Alloy | 125 °C | -40 C | 35 | 0.25 Ám | 10 Áin | 1 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Cantilever | Non Specified - Single Edge | Through Hole | Female | 3.18 mm | 0.125 in | 35 | Green | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Wire Wrap | Copper Alloy | 125 °C | -40 C | 35 | 0.25 Ám | 10 Áin | 1 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Cantilever | Non Specified - Single Edge | Through Hole | Female | 3.18 mm | 0.125 in | 35 | Green | 0.156 " | 3.96 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Solder | Copper Alloy | 125 °C | -40 C | 35 | 0.25 Ám | 10 Áin | 1 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Cantilever | Non Specified - Single Edge | Through Hole | Female | 3.18 mm | 0.125 in | 35 | Green | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Solder | Copper Alloy | 125 °C | -40 C | 35 | 0.25 Ám | 10 Áin | 1 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Cantilever | Non Specified - Single Edge | Through Hole | Female | 3.18 mm | 0.125 in | 35 | Green | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Wire Wrap | Copper Alloy | 125 °C | -40 C | 35 | 0.25 Ám | 10 Áin | 1 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Cantilever | Non Specified - Single Edge | Through Hole | Female | 3.18 mm | 0.125 in | 35 | Green | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm |
