C1321 Series

Catalog

TEST LEAD 18AWG 5000V RED 1000'

Part	Wire Gauge	Jacket Color	Voltage	Length	Length	Cable Type	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Ratings	Operating Temperature [Max]	Operating Temperature [Min]	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Material	Conductor Material	Length [x]	Length [x]	Length
Prysmian Group C1321.41.03	18 AWG	Red	5 kVDC	304.8 m	1000 ft	Test Lead	3.68 mm	0.145 "	ASTM B-33	90 °C	-40 C	1.14 mm	0.045 in	36 AWG	65	Rubber	Copper Annealed Tinned
Prysmian Group C1321.46.05	18 AWG	Yellow	5 kVDC			Test Lead	3.68 mm	0.145 "	ASTM B-33	90 °C	-40 C	1.14 mm	0.045 in	36 AWG	65	Rubber	Copper Annealed Tinned
Prysmian Group C1321.41.03	18 AWG	Red	5 kVDC	304.8 m	1000 ft	Test Lead	3.68 mm	0.145 "	ASTM B-33	90 °C	-40 C	1.14 mm	0.045 in	36 AWG	65	Rubber	Copper Annealed Tinned
Prysmian Group C1321.46.01	18 AWG	Black	5 kVDC	15.24 m 304.8 m	50 ft 1000 ft	Test Lead	3.68 mm	0.145 "	ASTM B-33	90 °C	-40 C	1.14 mm	0.045 in	36 AWG	65	Rubber	Copper Annealed Tinned	100 ft	30.5 m
Prysmian Group C1321.38.03	18 AWG	Red	5 kVDC	152.4 m	500 ft	Test Lead	3.68 mm	0.145 "	ASTM B-33	90 °C	-40 C	1.14 mm	0.045 in	36 AWG	65	Rubber	Copper Annealed Tinned
Prysmian Group C1321.46.03	18 AWG	Red	5 kVDC			Test Lead	3.68 mm	0.145 "	ASTM B-33	90 °C	-40 C	1.14 mm	0.045 in	36 AWG	65	Rubber	Copper Annealed Tinned
Prysmian Group C1321.46.01	18 AWG	Black	5 kVDC	15.24 m 152.4 m 304.8 m	50 ft 500 ft 1000 ft	Test Lead	3.68 mm	0.145 "	ASTM B-33	90 °C	-40 C	1.14 mm	0.045 in	36 AWG	65	Rubber	Copper Annealed Tinned	100 ft	30.5 m	Enter Number of Feet in Order Quantity
Prysmian Group C1321.38.01	18 AWG	Black	5 kVDC	152.4 m	500 ft	Test Lead	3.68 mm	0.145 "	ASTM B-33	90 °C	-40 C	1.14 mm	0.045 in	36 AWG	65	Rubber	Copper Annealed Tinned
Prysmian Group C1321.46.03	18 AWG	Red	5 kVDC			Test Lead	3.68 mm	0.145 "	ASTM B-33	90 °C	-40 C	1.14 mm	0.045 in	36 AWG	65	Rubber	Copper Annealed Tinned
Prysmian Group C1321.38.03	18 AWG	Red	5 kVDC	152.4 m	500 ft	Test Lead	3.68 mm	0.145 "	ASTM B-33	90 °C	-40 C	1.14 mm	0.045 in	36 AWG	65	Rubber	Copper Annealed Tinned
