TSM250 Series

Manufacturer: Taiwan Semiconductor Corporation

Catalog

MOSFET 2N-CH 60V 7A/30A 8DFN

Part	Input Capacitance (Ciss) (Max) @ Vds	Configuration	Drain to Source Voltage (Vdss)	Current - Continuous Drain (Id) @ 25°C	Rds On (Max) @ Id, Vgs [Max]	Package / Case	Supplier Device Package	Power - Max	Vgs(th) (Max) @ Id	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Technology	Gate Charge (Qg) (Max) @ Vgs	Power Dissipation (Max) [Max]	Drive Voltage (Max Rds On, Min Rds On) [Max]	Drive Voltage (Max Rds On, Min Rds On) [Min]	Operating Temperature	Vgs (Max)	FET Type	Power - Max [Max]	Gate Charge (Qg) (Max) @ Vgs [Max]	Input Capacitance (Ciss) (Max) @ Vds [Max]	Supplier Device Package [y]	Supplier Device Package [x]	Rds On (Max) @ Id, Vgs	Drive Voltage (Max Rds On, Min Rds On)	Power Dissipation (Max)
Taiwan Semiconductor Corporation TSM250NB06DCR RLG	1461 pF	2 N-Channel (Dual)	60 V	7 A 30 A	25 mOhm	8-PowerTDFN	8-PDFN (5x6)	2 W 48 W	4 V	Surface Mount	150 °C	-55 °C	MOSFET (Metal Oxide)	22 nC
Taiwan Semiconductor Corporation TSM250N02CX	535 pF		20 V	5.8 A	25 mOhm	SC-59 SOT-23-3 TO-236-3	SOT-23		800 mV	Surface Mount			MOSFET (Metal Oxide)	7.7 nC	1.56 W	1.8 V	4.5 V	150 °C	10 V	N-Channel
Taiwan Semiconductor Corporation TSM250N02DCQ	775 pF	2 N-Channel 2 N-Channel (Dual)	20 V	5.8 A	25 mOhm	6-VDFN Exposed Pad	6-TDFN (2x2)		800 mV	Surface Mount	150 °C	-55 °C	MOSFET (Metal Oxide)								620 mW	11 nC
Taiwan Semiconductor Corporation TSM250NB06LCV RGG			60 V	6 A 27 A		8-PowerWDFN	8-PDFN		2.5 V	Surface Mount	150 °C	-55 °C	MOSFET (Metal Oxide)	23 nC					20 V	N-Channel			1307 pF	3.1	3.15	25 mOhm	4.5 V 10 V	1.9 W 42 W
Taiwan Semiconductor Corporation TSM250N02DCQ RFG	775 pF	2 N-Channel (Dual)	20 V	5.8 A	25 mOhm	6-VDFN Exposed Pad	6-TDFN (2x2)		800 mV	Surface Mount	150 °C	-55 °C	MOSFET (Metal Oxide)								620 mW	11 nC
Taiwan Semiconductor Corporation TSM250NB06LDCR RLG	1314 pF	2 N-Channel (Dual)	60 V	6 A 29 A		8-PowerTDFN	8-PDFN (5x6)	2 W 48 W	2.5 V	Surface Mount	150 °C	-55 °C	MOSFET (Metal Oxide)	23 nC												25 mOhm
