HMC423 Series

DBL-BAL Mixer w/LO Amplifier SMT, 0.6 - 1.3 GHz

Catalog

DBL-BAL Mixer w/LO Amplifier SMT, 0.6 - 1.3 GHz

Part	Frequency [Min]	Frequency [Max]	Utilized IC / Part	Contents	Type	Mounting Type	Voltage - Supply	Package / Case	Package / Case [custom]	Package / Case	Supplier Device Package	Secondary Attributes	RF Type	Noise Figure	Current - Supply	Number of Mixers
Analog Devices 105190-HMC423MS8	600 MHz	1.3 GHz	HMC423MS8	Board(s)	Mixer
Analog Devices HMC423MS8TR	600 MHz	1.3 GHz				Surface Mount	3 V	8-MSOP 8-TSSOP	0.118 in	3 mm	8-MSOP	Up/Down Converter	CATV	8 dB	15 mA	1

Catalog

DBL-BAL Mixer w/LO Amplifier SMT, 0.6 - 1.3 GHz

Key Features

• Integrated LO Amp w/ Pdiss <50 mW

• Conversion Loss / Noise Figure: 8 dB

• Low LO Drive: 0 dBm

• Input IP3: +15 dBm

• Single Positive Supply: 3V @ 15 mA

Description
